Eye Bolt With Shoulder, 41/64 in ID, Steel, Powder Coat
Mfr # 1090768
Zoro # G2368147
CAD Available
product price: $8.19
/eaKey Features
CAD Drawing
Shoulder Style
With Shoulder
System of Measurement
Inch
Eye Inside Diameter
41/64 in
Material
Steel
Finish
Powder Coat
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
1090768
Zoro #
G2368147
UPC #
-
Country of Origin
United States
Dimensions
Eye Inside Diameter
41/64 in
Overall Length
1.31 in
Eye Outside Diameter
1-9/64 in
Eye Outside Dia.
1 9/64 in
Eye Inside Dia.
41/64 in
Overall Width
1 1/8 in
Ring Inner Diameter
5/8 in
Mounting Hole Diameter
1 in
Ring Thickness
1/4 in
Overall Depth
1/4 in
Details
CAD Available
Yes
Item
Eye Bolt
Shoulder Style
With Shoulder
System of Measurement
Inch
Material
Steel
Finish
Powder Coat
Eyebolt Type
Forged with Shoulder
Standards
MS-51930A
Number of Mounting Holes
1
Description
Pad Eye, Product Type Pad Eye, Material Carbon Steel, Finish Black Oxide, Number of Mounting Holes 1, Mounting Hole Diameter 1 in, Ring Inner Diameter 5/8 in, Ring Thickness 1/4 in, Overall Width 1 1/8 in, Overall Length 1 5/16 in, Overall Depth 1/4 in
