Dayton

DC Speed Control, 90/180VDC, NEMA 4/12

Dayton DC Speed Control, 90/180VDC, NEMA 4/12 2M171
Hover or click to zoom Tap to zoom
$577.53
  • Item: DC Speed Control
  • Enclosure: NEMA 4/12
  • Max. Amps: 10 A
See full product details
This item ships free.
Total: $577.53

Dayton #2M171 Specifications

  • Item: DC Speed Control
  • Enclosure: NEMA 4/12
  • Max. Amps: 10 A
  • Voltage Output: 0 to 90/180V DC
  • Speed Range: 50:1
  • Rotation: Reversible
  • External Switches: FWD/STOP/REV, ON/OFF
  • AC Input Voltage: 120/240V AC
  • DC Speed Control: SCR
  • Mount Type: Wall
  • Dynamic Braking: Yes
  • Shunt Wound Volts: 100/200V DC
  • Current/Torque Limit: Adjustable
  • Linear Acceleration: Fixed 1 to 3 sec
  • IR Compensation: Adjustable
  • HP @ Higher Volts: 1/4 to 2
  • Standards: cULus Listed
  • For Use With: For Packaging Equipment, Pumps, Fans, Blowers, Conveyors and Other Constant or Diminishing Torque
  • Power On Light: Yes
  • Includes: Run/Stop Switch, Built-in Transient and Surge Suppression
  • Depth: 5.5 in
  • Linear Deceleration: Fixed 0.5 sec
  • HP @ Lower Volts: 1/8 to 1
  • Accepts Tach Feedback: Yes
  • Operating Temp.: -10 Degrees to 45 Degrees C
  • Height: 9.5 in
  • Speed Regulation: +/-1% of Motor Base Speed
  • Width: 5 in
  • Series: Series 125
  • Maximum Linear Deceleration: 0.5 sec
  • Overall Width: 5 in
  • Operating Temperature: -10 Degrees to 45 Degrees C
  • Maximum Linear Acceleration: 1 sec
  • Minimum Linear Acceleration: 3 sec
  • NEMA Rating: NEMA 4
  • Higher Voltage Motor Output Power: 180 V DC
  • Enclosure Rating: NEMA 4
  • Overall Depth: 5.5 in
  • Shunt Wound Voltage: 100/200V DC
  • Overall Height: 9.5 in
  • Maximum Current: 10 A
  • Enclosure Type: Enclosed
  • Lower Voltage Motor Output Power: 90 V DC
  • Country of Origin (subject to change): United States

Description

The DAYTON 90/180Vdc SCR DC Speed Control is designed to provide speed control with a direct current. It features reversible rotation to make it easy to change the direction of your motor. To adjust the speed of the motor, you can use the external ON/OFF and FWD/STOP/REV switches. Included with the speed control is a run/stop switch, built-in transient and surge suppression. This speed control is designed with dynamic braking. To ensure safe operation, this speed control has a current limit and torque limit that can be adjusted to fit the needs of your application.
