  13. IEC Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing
Dayton IEC Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing 6EAV2 - main

IEC Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing

  • Mfr # 6EAV2

  • Zoro # G2451102

product price: $23.29
/ea

Key Features

Auxiliary Contact Form
1NO
Coil Voltage
24V AC
Number of Poles
3
Reversing Capability
Non-Reversing
Number of Auxillary Contacts
1
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6EAV2
Zoro #
G2451102
UPC #
190735361375
Country of Origin
India

Dimensions

Overall Height
1.77 in
Overall Width
1.77 in
Overall Depth
3.18 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NO
Coil Voltage
24V AC
Number of Poles
3
Reversing Capability
Non-Reversing
Number of Auxillary Contacts
1
Standards
CSA, UL Listed
Enclosure NEMA Rating
No Enclosure
Reversing
No
HP @ 1 Phase - 230V
2
HP @ 3 Phase - 575V
10 hp
Full Load Current - Inductive
12:00 AM
Horsepower @ Three Phase - 208V AC
3 hp
Horsepower @ Three Phase - 480V AC
7 1/2 hp
Embedded Surge Suppressor
No
Horsepower @ Single Phase - 120V AC
1 hp
Full Load Current - Resistive
25 A
Horsepower @ Single Phase - 240V AC
2 hp
Includes Auxiliary Contacts
Yes
NEMA Enclosure Rating
No Enclosure
Frequency
50/60 Hz
Horsepower @ Three Phase - 240V AC
3 hp
Horsepower @ Three Phase - 600V AC
10 hp
Contactor Style
IEC

Description

The DAYTON IEC Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing is an IEC-style, electrically operated switching device used to control power circuits. It uses an electromagnetic coil to open or close the main contacts, and is configured for 3 poles with a 24 V AC coil. This model includes 1 normally open auxiliary contact and has no embedded surge suppressor or enclosure. It is rated for operation within the specified frequency ranges and complies with recognized safety standards. Its dimensions are 3.18 in deep, 1.77 in wide, and 1.77 in high. Reversing capability is not supported.

Action: Non-Reversing

  • Poles: 3
  • Coil Voltage: 24 V AC
  • Auxiliary Contacts: 1NO
  • Auxiliary Contact Form: 1NO
  • Includes Auxiliary Contacts: Yes
  • Embedded Surge Suppressor: No
  • Enclosure: No Enclosure
  • Frequency: 50/60 Hz
  • Full Load Amps (Inductive/Resistive): 12 A / 25 A
  • Full Load Current (Inductive/Resistive): 12 A / 25 A
  • HP @ Single Phase: 120V = 1 hp; 230V = 2 hp; 240V = 2 hp
  • HP @ Three Phase: 208V = 3 hp; 240V = 3 hp; 480V = 7 1/2 hp; 575V = 10 hp
  • Standards: CSA, UL Listed
  • Height: 1.77 in
  • Width: 1.77 in
  • Depth: 3.18 in
  • Item: IEC Magnetic Contactor
