Dayton IEC Magnetic Contactor, No Auxiliary Contacts, 24V AC, 4 P, Non-Reversing 6EAY5 - main

IEC Magnetic Contactor, No Auxiliary Contacts, 24V AC, 4 P, Non-Reversing

  • Mfr # 6EAY5

  • Zoro # G2810735

product price: $57.69
/ea

Key Features

Auxiliary Contact Form
No Auxiliary Contacts
Coil Voltage
24V AC
Number of Poles
4
Reversing Capability
Non-Reversing
Number of Auxillary Contacts
4
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6EAY5
Zoro #
G2810735
UPC #
190735361702
Country of Origin
India

Dimensions

Overall Height
2.2 in
Overall Depth
3.75 in
Overall Width
2.2 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
No Auxiliary Contacts
Coil Voltage
24V AC
Number of Poles
4
Reversing Capability
Non-Reversing
Number of Auxillary Contacts
4
Standards
CSA, UL Listed
Special Features
Main Contact Configuration 2NC/2NO
HP @ 1 Phase - 230V
3
Reversing
No
Enclosure NEMA Rating
No Enclosure
Number of Normally Closed Main Contacts
2
NEMA Enclosure Rating
No Enclosure
Contactor Style
IEC
Horsepower @ Single Phase - 120V AC
2 hp
Horsepower @ Single Phase - 240V AC
3 hp
Frequency
50/60 Hz
Includes Auxiliary Contacts
Yes
Embedded Surge Suppressor
No
Full Load Current - Resistive
40 A
Number of Normally Open Main Contacts
2
Full Load Current - Inductive
25 A

Description

The DAYTON IEC Magnetic Contactor, No Auxiliary Contacts, 24V AC, 4P, Non-Reversing is an IEC-style, electromagnetically operated switch rated for operation within the specified electrical parameters. It uses a 24 V AC coil to operate and has four poles with non-reversing operation; includes auxiliary contacts as specified.

Action: Non-Reversing

  • Coil Voltage: 24 V AC
  • Coil Volts: 24 V AC
  • Contactor Style: IEC
  • Depth: 3.75 in
  • Embedded Surge Suppressor: No
  • Enclosure NEMA Rating: Does not include an enclosure
  • Frequency: 50/60 Hz
  • Full Load Amps-Inductive: 25 A
  • Full Load Amps-Resistive: 40 A
  • Full Load Current - Inductive: 25 A
  • Full Load Current - Resistive: 40 A
  • HP @ 1 Phase - 120V: 2 hp
  • HP @ 1 Phase - 230V: 3 hp
  • HP @ 1 Phase - 240V: 3 hp
  • Height: 2.2 in
  • Includes Auxiliary Contacts: Yes
  • Item: IEC Magnetic Contactor
  • NEMA Enclosure Rating: Does not include an enclosure
  • Number of Auxillary Contacts: 4
  • Number of Normally Closed Main Contacts: 2
  • Number of Normally Open Main Contacts: 2
  • Number of Poles: 4
  • Standards: CSA, UL Listed
  • Width: 2.2 in
  • Reversing: No
  • Reversing Capability: Non-Reversing
  • Special Features: Main Contact Configuration 2NC/2NO
  • Overall Depth: 3.75 in
  • Overall Height: 2.2 in
  • Overall Width: 2.2 in
  • Hz: 50/60
  • Frequency: 50/60 Hz
