Dayton Incandescent Photocontrol, 1,800 W, Yellow 26WA86 - main

Incandescent Photocontrol, 1,800 W, Yellow

  • Mfr # 26WA86

  • Zoro # G9506971

product price: $12.19
/ea

Key Features

Foot Candles On
10.0 to 20.0
Foot Candles Off
30 to 60
Temp. Range
-40 Degrees to 158 Degrees F
Housing Material
Polycarbonate
Enclosure Type
Raintight
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
26WA86
Zoro #
G9506971
UPC #
190735210888
Country of Origin
China

Dimensions

Manufacturers Warranty Length
3 yr
Length
3 3/8 in
Depth
2 3/8 in
Width
3 3/8 in
Overall Height
3.38 in

Details

Item
Photocontrol
Foot Candles On
10.0 to 20.0
Foot Candles Off
30 to 60
Temp. Range
-40 Degrees to 158 Degrees F
Housing Material
Polycarbonate
Enclosure Type
Raintight
Description/Special Features
Built in Delay
For Use With
Area Lighting, Billboard Lighting, Car Lot Lighting, Municipal Lighting, Parking Lot Lighting, Roadway Lighting, Security Lighting, Street Lighting
Setting
Dusk to Dawn
Contact Form
SPST
Mounting Style
Turn Lock
Ballast Current - Maximum
15 A
On Illumination - Maximum
20 fc
Compatible Lighting
Incandescent
AC Operating Voltage
480V AC
Body Color
Yellow
Off Illumination - Maximum
60 fc
Wattage - Maximum
1,800 W
Operating Temperature - Maximum
158 Degrees F
Off Illumination - Minimum
30 fc
Operating Temperature - Minimum
-40 Degrees F
On Illumination - Minimum
10 fc
Incandescent Current - Maximum
15 A
Features
Built-In Delay

Description

Photocontrol, Mounting Turn-Lock, Voltage 480V AC, Max. Wattage 1,800, Max. Incandescent Amps 15 A, Max. Ballast Amps 15 A, 10.0 to 20.0 Foot Candles On, 30 to 60 Foot Candles Off, Color Yellow, Temp. Range -40 Degrees to 158 Degrees F, Length 3 3/8 in, Width 3 3/8 in, Depth 2 3/8 in, Enclosure Type Raintight, Contact Form SPST, Housing Material Polycarbonate, Setting Dusk to Dawn
