  12. /
  13. Low Headroom Chain Hoist, 2000 lb., 10 ft.
Shop All Manual Chain Hoists
Dayton

Low Headroom Chain Hoist, 2000 lb., 10 ft.

original price: $156.76
10% off
new price: $140.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Load Capacity 2,000 lb
  • Hoist Lift 10 ft
  • Hoist Mount Hook Mounted - No Trolley
  • Hoist Overload Protection No
  • Pull to Lift Rated Load 67 lb
See all product information

Product Information

Dimensions

Housing Length 5 5/8 in
Housing Width 5 3/4 in
Housing Depth 5 in
Manufacturers Warranty Length 1 yr
Minimum Retracted Length 13 3/8 in
Maximum Lifting Length 10 ft
Mfr. Warranty Length 1 yr
Body Width 5 5/8 in
Body Depth 5 1/16 in
Lifting Hook Opening Width 1 1/8 in
Chain Length 10 3/4 ft

Details

Load Capacity 2,000 lb
Hoist Lift 10 ft
Hoist Mount Hook Mounted - No Trolley
Hoist Overload Protection No
Pull to Lift Rated Load 67 lb
Min. Between Hooks 13 1/2 in
Hook Opening 1 7/64 in
Includes Safety Latch Hooks
Standards ANSI/ASME B30.16
Item Manual Chain Hoist
Trolley Configuration Hook Mounted - No Trolley
Brake Weston Style, Double Disc Brake
Color Red
Features Featuring a Compact Design, These Low-Headroom Chain Hoists are Ideal for use in Small Facilities, Friction-Reducing Rollers and Ball Bearings, Jamproof Chain Guides
Body Material Steel
Chain Finish Black Tempered, Zinc Plated
Chain Material Alloy Steel
Overload Protection Included No
Number of Reeves 1
Chain Grade Grade 80
Headroom 13 1/2 in
Lifting Hook Type Hook with Safety Latch
Includes Brake Brake Included
Lifting Hook Material Alloy Steel
Power Source Manual
Body Finish Powder Coated
Operating Position Vertical
Maximum Lifting Capacity 2,000 lb
For Outdoor Use Yes
Mount Type Hook Mounted - No Trolley
Included Components Safety Latch Hooks
Includes Clutch Clutch Included
Number of Load Chains 1
Brake Type Double Disc Brake, Weston Style

Description

Manual Chain Hoist, Chain Length 10 3/4 ft, For Minimum Beam Flange Width Not Applicable, For Maximum Beam Flange Width Not Applicable, Headroom 13 1/2 in, Includes Brake Brake Included, Lifting Hook Type Hook with Safety Latch, Maximum Lifting Capacity 2,000 lb, Maximum Lifting Length 10 ft, Mount Type Hook Mounted - No Trolley, Body Depth 5 1/16 in, Body Material Steel, Body Width 5 5/8 in, Brake Type Double Disc Brake, Weston Style, Chain Grade Grade 80, Chain Material Alloy Steel, Color Red
