  5. Turbine Pump, 3/4 HP, 3 Ph, 2.5/1.2 Amp

This item is Discontinued.

Dayton Turbine Pump, 3/4 HP, 3 Ph, 2.5/1.2 Amp 4JPF5

Turbine Pump, 3/4 HP, 3 Ph, 2.5/1.2 Amp (Discontinued)

  • Mfr # 4JPF5
  • Zoro # G1204901
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
4JPF5
Zoro #
G1204901
UPC #
190735327098
Country of Origin
India

Dimensions

Width
6 3/4 in
Height
6 1/2 in
Overall Width
6.75 in
Overall Height
6.5 in
Compatible Discharge Pipe Size
1 in
Intake and Discharge Size
1 in , 1 in
Compatible Intake Pipe Size
1 in

Details

HP
3/4 hp
Voltage
208-230/460
Wetted Materials
Bronze, Carbon, Cast Iron,Buna-N, Ceramic and 316 Stainless Steel
Seal Material
Buna-N with Carbon and Ceramic Faces & 316 Stainless Steel Spring
Max. Pressure
120 psi
GPM @ 20 PSI
8.2
GPM @ 60 PSI
6.4
Amps
2.7-2.5/1.2
Max. Case Pressure
200 psi
Housing Material
Cast Iron with nickel plating
Motor Type
3-Phase
GPM @ 90 PSI
4.9
Hz
60
Inlet
1 in
Impeller Type
Open
GPM @ 80 PSI
5.4
Inlet (In.)
1
GPM @ 50 PSI
6.8
Frame
56J
Outlet
1 in
Inlet Pressure
122 psi
Item
Turbine pump
Motor Enclosure
ODP
Impeller Material
Bronze
Agency Compliance
Motor is UL Recognized
GPM @ 40 PSI
7.3
Best Efficiency GPM @ Head
5.4 @ 80 ft
Motor RPM
3,450 RPM
Includes
OIPM
Max. Specific Gravity
1
Phase
3
Duty
Continuous
GPM @ 100 PSI
4.3
GPM @ 75 PSI
5.7
GPM @ 30 PSI
7.8
GPM @ 10 PSI
8.6
Bearing Type
Ball
Features
Designed to Handle Liquids with Entrained Air
Standards
UL Listed
Flow Rate @ 20 psi
8.2 gpm
Motor Enclosure Type
ODP
Specific Gravity (Maximum)
1
Shut Off Pressure (Maximum)
120 psi
Minimum Flow Rate
4.3 gpm
Seal Type
Mechanical Seal
Flow Rate @ 100 psi
4.3 gpm
Motor Frame Designation
56J
Wetted Material
316 Stainless Steel, Bronze, Buna-N, Carbon, Cast Iron, Ceramic
Flow Rate @ 60 psi
6.4 gpm
Flow Rate @ 90 psi
4.9 gpm
Maximum Flow Rate
8.6 gpm
Frequency
60 Hz
Case Pressure (Maximum)
200 psi
Priming
Self-Priming
Maximum RPM
3,450 RPM
Nameplate Voltage
208-230/460V AC
Flow Rate @ 30 psi
7.8 gpm
Flow Rate @ 40 psi
7.3 gpm
Horsepower
3/4 hp
Operation
Manual
Best Efficiency Head
80 ft
Impeller Design
Open
Pump Housing Material
Cast Iron
Duty Cycle
Continuous
NPSHr
122 psi
Flow Rate @ 50 psi
6.8 gpm
Flow Rate @ 10 psi
8.6 gpm
Flow Rate @ 80 psi
5.4 gpm

Description

Turbine pump, Phase Three, Pump Housing Material Cast Iron, Motor Enclosure Open Dripproof, Horsepower 3/4 hp, Nameplate Voltage 208-230/460V AC, Shut Off Pressure (Maximum) 120 psi, Maximum Flow Rate 8.6 gpm, Flow Rate @ 10 psi 8.6 gpm, Flow Rate @ 20 psi 8.2 gpm, Flow Rate @ 30 psi 7.8 gpm, Compatible Intake Pipe Size 1 in, Compatible Discharge Pipe Size 1 in, Motor Type 3-Phase, Best Efficiency Head 80 ft, Case Pressure (Maximum) 200 psi, Duty Cycle Continuous
