Parallel Gripper, Precision, Directconnect
- Mfr # DPP-20M-38
- Zoro # G1145551
product price:Â
$
2,588.99
/ea
Free Shipping & Returns
Key Features
Overall Height
55.63 mm
Overall Width
175.5 mm
Overall Length
46 mm
Weight
1.41 kg
Product Type
Parallel Gripper,Precision,Directconnect
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- DPP-20M-38
- Zoro #
- G1145551
- UPC #
- -
- Country of Origin
- United States
- Item
- Parallel Gripper,Precision,Directconnect
- Weight
- 1.41 kg
- Product Type
- Parallel Gripper,Precision,Directconnect
- IP Rating
- IP43
- Repeatability
- +/-0.01 mm
- Minimum Operating Pressure
- 0.3 bar
- Displacement
- 12.8 cc
- Maximum Actuation Time
- 0.24 sec
- Maximum Operating Temperature
- 80 Degrees C
- Accuracy
- +/-0.03 mm
- Operation Type
- Synchronous
- System of Measurement
- Metric
- Seal Material
- Buna-N
- Series
- DPP
- Total Rated Grip Force @ 100 psi
- 423 N
- Minimum Operating Temperature
- -35 Degrees C
- Maximum Operating Pressure
- 7 bar
Dimensions
- Overall Height
- 55.63 mm
- Overall Width
- 175.5 mm
- Overall Length
- 46 mm
- Stroke Length
- 38.1 mm
- Open Width
- 161 mm
- Maximum Finger/Jaw Length
- 152.4 mm
- Inlet Size
- M5
- Wire Rope Length
- 46 mm
- Length
- 46 mm
Description
Parallel Gripper,Precision,Directconnect, Series DPP, Open Width 161 mm, Stroke Length 38.1 mm, Maximum Operating Pressure 7 bar, Minimum Operating Pressure 0.3 bar, Overall Length 46 mm, Overall Width 175.5 mm, Overall Height 55.63 mm, Inlet Size M5, Maximum Operating Temperature 80 Degrees C, Minimum Operating Temperature -35 Degrees C, Weight 1.41 kg, System of Measurement Metric, Total Rated Grip Force @ 100 psi 423 N, IP Rating IP43, Seal Material Buna-N, Displacement 12.8 cc
