Mechanical Exit Devices
Mfr # V40 EB LD 628 99 36
Zoro # G721829192
product price:Â
$
461.99
/ea
Free Shipping & Returns
Key Features
Exit Device Type
Rim
Hand Orientation
Non-Handed
Standards
ADA, ANSI 156.3 - 2008, ANSI/BHMA A156.3, California State Fire Marshall 4140-0127:105 and 3725-0127:108, cULus Listed, Miami-Dade County, Florida NOA 15-0415.08, NFPA 80 and 101 for Life Safety, State of Florida Approval FL9052, UBC 97, Standard 7-2 and UL10B/UL10C for Positive Pressure
Door Thickness - Maximum
2 1/4 in
Door Thickness - Minimum
1 3/4 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- V40 EB LD 628 99 36
- Zoro #
- G721829192
- UPC #
- 840067654316
- Country of Origin
- United States
Dimensions
- Door Thickness - Maximum
- 2 1/4 in
- Door Thickness - Minimum
- 1 3/4 in
- Fits Stile Width
- 4 in
- Door Width - Maximum
- 36 in
Details
- Exit Device Type
- Rim
- Hand Orientation
- Non-Handed
- Standards
- ADA, ANSI 156.3 - 2008, ANSI/BHMA A156.3, California State Fire Marshall 4140-0127:105 and 3725-0127:108, cULus Listed, Miami-Dade County, Florida NOA 15-0415.08, NFPA 80 and 101 for Life Safety, State of Florida Approval FL9052, UBC 97, Standard 7-2 and UL10B/UL10C for Positive Pressure
- Exit Bar Style
- Touchbar
- Lockdown Type
- Less Dogging
- Lockset Type
- Electrical
- UL Fire Rating
- UL10B, UL10C
- ANSI Grade
- 1
- Color
- Matte Silver
- Product Type
- Exit Device
- ANSI/BHMA Finish
- Satin Aluminum, Clear Anodized
- Voltage
- 24 V AC/DC
- ADA Compliant
- Yes
- Lockset Function
- Exit
- Item
- Exit Device
Description
Exit Device, Rim, Less Dogging, 24 V AC/DC, Fits Stile Width 4 in, Yes, Standards ADA, ANSI 156.3 - 2008, ANSI/BHMA A156.3, California State Fire Marshall 4140-0127:105 and 3725-0127:108, cULus Listed, Miami-Dade County, Florida NOA 15-0415.08, NFPA 80 and 101 for Life Safety, State of Florida Approval FL9052, UBC 97, Standard 7-2 and UL10B/UL10C for Positive Pressure, Outside Trim Type Not Included, Lockset Function Exit
