Indexable Boring Bar, E06M-SCLCR-2, 6 in L, Carbide, 80 Degrees Diamond Insert Shape

  • Mfr # 73310159595

  • Zoro # G7829211

product price:
$
275.99
/ea
Free Shipping & Returns

Key Features

Overall Length
6 in
Shank Material
Carbide
Insert Shape
80 Degrees Diamond
Insert Size
21.5
Mounting Style
Screw Lock
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
73310159595
Zoro #
G7829211
UPC #
-
Country of Origin
United States
Item
Indexable Boring Bar
Shank Material
Carbide
Insert Shape
80 Degrees Diamond
ANSI Code
E06M-SCLCR-2
Mounting Style
Screw Lock
Material
Carbide
Cutting Direction
Right Hand
Insert Screw
TS-25.45-6M2
Style
E06M-SCLCR-2
Shank
Round
Type
Carbide Coolant-Thru
Inscribed Circle
0.25"
Lead Angle
15
Min. Bore
0.396"
Rake
Negative
Number of Inserts
1
ISO Number
E06M-SCLCR-2
Insert Holding Type
Clamp
Number of Coolant Holes
1
Compatible Hardware
T-8 Torx Key, TS-25.45-6M2 Insert Torx Screw
Side Cutting Edge Angle
-5 Degrees
Center to Cutting Tip
0.1980 in
Coolant Fed
Coolant Through
Cutting Application
Boring
Vibration Dampening
Yes
Insert Clearance Angle
5 Degrees
Features
Surface Finish Compared to Steel Boring Bars
Insert Style
CC
Insert Inscribed Circle
1/4 in

Description

Indexable Boring Bar, Insert Shape 80 Degrees Diamond, Overall Length 6 in, E06M-SCLCR-2, 0.1980 in, T-8 Torx Key, TS-25.45-6M2 Insert Torx Screw, Coolant Through, Boring, Right Hand
