Shop All Fire and Smoke Dampers
Ductmate

Sandwich Style Insulated Round Duct

product price: $86.25
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Shape Rectangular
  • Includes Self-Adhesive Template
  • Material Steel
  • Standards ASTM D746, UL 94 HB, UL 94 HF 1
  • Door Height 4 in
See all product information

Product Information

Dimensions

Door Height 4 in
Rough Opening Height 3 7/8 in
Duct Diameter 7 in to 9 in
Door Width 8 in
Rough Opening Width 7 7/8 in
Duct Radius 7" to 9"
Mounting Stud Length 2 in
For Nominal Duct Diameter 7 in, 8 in, 9 in

Details

Item Duct Access Door
Shape Rectangular
Includes Self-Adhesive Template
Material Steel
Standards ASTM D746, UL 94 HB, UL 94 HF 1
Finish Galvanized
Hinges None
Temp. Range 200 Degrees F max
Latch Type Knobs
For Duct Shape Round
Observation Port Material Steel
Door Shape Rectangular
Minimum Temperature Rating -20 Degrees F
Door Thickness 7/8 in
Maximum Temperature Rating Standard Temperature
Number of Mounting Stud 2
For Media Type Air
Maximum Pressure Rating 20 in wc
Product Type Access Door
Hinge Style None
Fire Rating Not Rated
Insulation Material Fiberglass
Material Thickness 22 ga
Material Fabrication Stamped

Description

Duct Access Door, Door Height 4 in, Door Shape Rectangular, Door Thickness 7/8 in, Door Width 8 in, Fire Rating Not Rated, For Nominal Duct Diameter 7 in, 8 in, 9 in, Hinge Style None, Insulation Material Fiberglass, Latch Type Knobs, Material Thickness 22 ga, Maximum Temperature Rating 200 Degrees F, Mounting Stud Length 2 in, Number of Mounting Stud 2, Observation Port Height Not Applicable, Observation Port Material Steel, Observation Port Width Not Applicable, Rough Opening Height 3 7/8 in
