Duro Pressure Gauge, 0 to 300 psi, 2 in Dial, 3/4 in FGHT, Top Location, Steel Case Material 18C830 - main

Pressure Gauge, 0 to 300 psi, 2 in Dial, 3/4 in FGHT, Top Location, Steel Case Material

  • Mfr # 18C830

  • Zoro # G4722365

product price:  $8.19
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Top
Process Connection Size
3/4 in
Process Connection Type
FGHT
Dial Size (In.)
2 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
18C830
Zoro #
G4722365
UPC #
-
Country of Origin
China

Dimensions

Process Connection Size
3/4 in
Dial Size (In.)
2 in
Nominal Dial Size
2 in
Gauge Case Diameter
2 in
Gauge Case Depth
1.3 in
Nominal Dial Diameter
2 in
Manufacturer Warranty Length
1 yr

Details

Item
Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Top
Process Connection Type
FGHT
Application
Water Pressure Testing
Gauge Case Material
Steel
Lens Material
Acrylic
Primary Pressure Range
0 to 300
Primary Scale Units
psi
Liquid-Filled Case
No
Panel-Mountable
No
Case Color
Black
For Use With
Non-Explosive Gas Or Liquid That Do Not Crystalize And Corrode Copper Alloy
Graduations
50 psi
Smallest Graduation
5 psi
Gauge Application
Home Water Pressure Testing
Calibration Certificate Included
No
Gauge Primary Range Smallest Graduation
5
Gauge Special Options
Maximum Reading Pointer
Socket Material
Copper Alloy
Case Material
Steel
Wetted Materials
Copper
Connection Type
FGHT
Sensor Material
Copper Alloy
Freeze Resistant Movement
No
Pressure Gauge Type
Home Water Line Test Kit
Ambient Operating Temperature Range
32 Degrees to 140 Degrees F
Primary Scale Minor Graduations
5
Accuracy Scale
Mid-Scale
Compatible Process Media
Non-Corroding, Non-Clogging
Dial Color
White
Scale Type
Single
Pressure Range Type
Pressure
Pointer Color
Black, Red
Process Connection Gender
Female
Maximum Pressure
300
Operating Temperature Range
32 Degrees to 140 Degrees F
Primary Scale Numeric Increments
50
Process Media Temperature - Minimum
40 Degrees F
Sensor Type
Bourdon Tube
Operating Temperature - Minimum
32 Degrees F
Number of Pointers
2
Over-Pressure Limit
30% of Full Scale
Operating Temperature - Maximum
140 Degrees F
Gauge Case Finish
Paint Coat
Primary Scale Pressure Measurement - Minimum
0 psi
Process Media Temperature - Maximum
140 Degrees F
Primary Scale Pressure Measurement - Maximum
300 psi
Primary Scale Color
Black
Pointer Material
Aluminum
Dial Face Material
Aluminum
Accuracy Grade
ASME B40.100

Description

Pressure Gauge, Gauge Type Max Reading Water Test, Dial Size 2 In., Range 0 to 300 psi, Connection Size 3/4 In. Female Hose Thread, Connection Location Top, Smallest Graduation 5 psi, Accuracy +/-3-2-3 Percent, Case Material Steel, Case Color Black, Socket Material Copper Alloy HPb59-1, Tube Material Copper Alloy QSn4-0.3, Lens Material Acrylic, Ring Material Chrome Plated, Operating Temp. Range 32 Degrees to 140 Degrees F

Restrictions

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
This is a restricted item in the USA. It cannot be used for potable water applications.
