Duro Vacuum Gauge, 6" Dial Size 6.2020113E7 - main

Vacuum Gauge, 6" Dial Size

  • Mfr # 6.2020113E7

  • Zoro # G4431581

product price: $121.99
/ea
Free Shipping & Returns

Key Features

Liquid Filled
No
Gauge Nominal Dial Size
6 in
Gauge Connection Type
MNPT
Gauge Connection Size
1/4 in
Gauge Connection Location
Bottom
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6.2020113E7
Zoro #
G4431581
UPC #
-
Country of Origin
United States

Dimensions

Gauge Nominal Dial Size
6 in
Gauge Connection Size
1/4 in
Connection Size
1/4 in NPT
Manufacturers Warranty Length
1 yr
Nominal Dial Size
6 in
Case Depth
2.32 in
Case Diameter
6.56 in
Manufacturer Warranty Length
1 yr
Process Connection Size
1/2 in
Nominal Dial Diameter
6 in

Details

Liquid Filled
No
Gauge Connection Type
MNPT
Gauge Connection Location
Bottom
Gauge Primary Range Units
in Hg
Gauge Secondary Range Units
Bar
Gauge Lens Material
Glass
Gauge Accuracy
+/-0.50%
Gauge Primary Range Smallest Graduation
1
Range
30 in Hg Vac to 0
Gauge Primary Range Numbered Graduations
5
For Use With
Media Compatible with 316L Stainless Steel
Connection Location
Bottom
Gauge Secondary Range Values
0 to 10
Gauge Sensor Material
316 Stainless Steel
Gauge Case Material
Aluminum
Case Color
Black
Series
Series 20
Gauge Case Color
Black
Gauge Socket Material
316 Stainless Steel
Graduations
1 in Hg
Gauge Primary Range Values
-30 to 0
Operating Temp. Range
-30 Degrees to 250 Degrees F
Smallest Graduation
1 in Hg
Calibration Certificate Included
No
Item
Industrial Vacuum Gauge
Panel-Mountable
Yes
Hazardous Location Rating
Not Rated
Case Material
Aluminum
Accuracy Grade
ASME B40.100 Grade 2A
Bezel Mounting Type
Threaded
Includes Vent Plug
No
Blowout Safety Back
No
Gauge Case Liquid
None
Standards
ASME/ANSI
Case Construction
Corrosion Resistant
Includes Calibration Certificate
No
Pointer Characteristics
Lightweight Balanced Construction with Micrometer Adjustment
Dial Face Material
Aluminum
Accuracy Scale
Full Scale
Freeze Resistant Movement
No
Primary Scale Units
in Hg
Lens Material
Glass
Secondary Pressure Range
-1 to 0
Process Connection Location
Bottom
Pressure Range Type
Vacuum
Dry Dampening Feature
None
Process Connection Gender
Male
Sensor Material
Stainless Steel
Includes Mounting Hardware
No
Sensor Type
Bourdon Tube
Primary Scale Minor Graduations
0.2
Application
Chemical Industries, Oil and Gas Industry
Movement Type
Rotary
Movement Material
Stainless Steel
Pressure Gauge Type
Industrial Pressure Gauge
Scale Type
Dual
Dial Color
White
IP/NEMA Rating
Not Rated
Removable Bezel
Yes
Non-Sparking
No
Cleaned for Oxygen Service
No
Vibration Resistance
None
Process Connection Type
NPT
Primary Pressure Range
30 to 0
Secondary Scale Units
bar
Field Fillable
No
Socket Material
Stainless Steel
Ambient Operating Temperature Range
-30 Degrees to 250 Degrees F
Accuracy
+/-0.5%
Liquid-Filled Case
No
Includes
Pulsation Restrictor
Primary Scale Vacuum Measurement - Minimum
0 in Hg
Primary Scale Pressure Measurement - Maximum
30 in Hg
Process Media Temperature - Minimum
-65 Degrees F
Operating Temperature - Maximum
250 Degrees F
Compatible with Brand
Universal
Primary Scale Vacuum Measurement - Maximum
30 in Hg
Secondary Scale Vacuum Measurement - Minimum
-1 bar
Primary Scale Pressure Measurement - Minimum
30 in Hg
Secondary Scale Vacuum Measurement - Maximum
0 bar
Pointer Color
Black
Process Media Temperature - Maximum
240 Degrees F
IP Rating
IP65
Operating Temperature - Minimum
-30 Degrees F
NEMA Enclosure Rating
4
Case Finish
Polished Stainless Steel

Description

Industrial Vacuum Gauge, Nominal Dial Size 6 in, Accuracy +/-0.5 Percent, Gauge Case Material Aluminum, Process Connection Type NPT, Process Connection Gender Male, Lens Material Glass, Process Connection Size 1/2 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating Not Rated, Primary Pressure Range 30 to 0, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Industrial Pressure Gauge, Liquid-Filled Case No
