  9. Differential digital pressure transmitter, range 0-0.25" w.c.
Dwyer Instruments Differential digital pressure transmitter, range 0-0.25" w.c. DM-002 - main

Differential digital pressure transmitter, range 0-0.25" w.c.

  • Mfr # DM-002

  • Zoro # G0017351

product price: $199.99
/ea
Free Shipping & Returns

Key Features

Pressure Range (In. WC)
0.25 to 0 to 0.25
Accuracy
+/-1% of Full Scale
Output
4 to 20mA DC
Power Required
10 to 35V DC
Process Connection Type
Hose Barb
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
DM-002
Zoro #
G0017351
UPC #
-
Country of Origin
United States

Dimensions

Process Connection Size
1/4 in
Diameter - Transmitter
4.75 in
Overall Depth - Transmitter
1.69 in
Process Connection Size - Transmitter
1/8 in
Overall Length
1.69 in
Housing Length
4 3/4 in
Diameter
4.75 in
Housing Height
4 3/4 in
Overall Diameter
4.75 in

Details

Item
Indicating Differential Transmitter
Pressure Range (In. WC)
0.25 to 0 to 0.25
Accuracy
+/-1% of Full Scale
Output
4 to 20mA DC
Power Required
10 to 35V DC
Process Connection Type
Hose Barb
Connection Location
Side
Operating Temp. - Transmitter
20 Degrees to 120 Degrees F
Series
DM-002
Standards
CE, RoHS
Pressure Range Minor Div.
0.005 in wc
Wiring Entry - Transmitter
None
Connection
1/8" Barbed Fitting
Loop Resistance
0 to 1250 ohms
Transmitter Type
Compound Transmitter
Shape - Transmitter
Round
Output - Transmitter
4 to 20mA DC
Display - Transmitter
3-1/2 Digit LCD
Accuracy - Transmitter
+/-1.00% Full Scale
Connection Location - Transmitter
Side
Power Required - Transmitters
10 to 35V DC
Includes
Instructions
Range Units - Transmitter
in wc/in wc
Process Connection Type - Transmitter
Hose Barb
Output Accuracy
+/-1% Full Scale
Range Values - Transmitter
-0.25 to 0 to 0.25
Electrical Connections - Transmitter
Screw Terminals
Thermal Error
+/-0.055%
Display Units
bar, in wc, kPa, mbar, mm wc, psi
Features
Zero and Span Controls
Display Type
Digital
Number of Digits
3 1/2
Display Screen Type
LCD
Electrical Connections
Screw Terminals
Shape
Round
Primary Scale Units
in wc
Maximum Loop Resistance
1250 Ohm
Primary Scale Range
0 to +/-.250 in wc
Minimum Operating Temperature
20 Degrees F
Number of Wires
2
Maximum Operating Temperature
120 Degrees F
NIST Traceable Certificate
No
For Use With Media Type
Air, Compatible Gases, Non-Combustible Gases
Minimum Pressure
0 in wc
Housing Material
Glass
Weight
4.8 oz
Overpressure
10 psi
Maximum Pressure
0.25 in wc
Pressure Units
in wc
Digital Display Screen Type
LCD
Pressure Measurement - Maximum
0.3 in wc
Process Media Temperature - Minimum
20 Degrees F
Pressure Measurement - Minimum
0 in wc
Includes NIST-Traceable Calibration Certificate
No NIST-Traceable Calibration Certificate Included
Input Voltage
10 to 35V DC
Loop Resistance - Maximum
1250 Ohm
Output Power
4 to 20mA DC
Process Connection Location
Side
Process Media Temperature - Maximum
120 Degrees F
Electrical Connection
Screw Terminals

Description

Indicating Differential Transmitter, Output 4 to 20mA DC, Maximum Pressure 0.25 in wc, Minimum Pressure 0 in wc, Overpressure 10 psi, Accuracy +/-1 Percent of Full Scale, Number of Wires 2, Power Required 10 to 35V DC, Process Connection Size 1/4 in, Process Connection Type Hose Barb, Series DM-002, Electrical Connections Screw Terminals, NIST Traceable Certificate No, Display Type Digital, Housing Material Glass, Connection Location Side, Diameter 4.75 in, Display Screen Type LCD
