  9. Differential pressure transmitter, 0 to 3" w.c., 4-20 mA.
Dwyer Instruments Differential pressure transmitter, 0 to 3" w.c., 4-20 mA. 616KD-02 - main

Differential pressure transmitter, 0 to 3" w.c., 4-20 mA.

  • Mfr # 616KD-02

  • Zoro # G5475224

product price: $117.99
/ea
Free Shipping & Returns

Key Features

Pressure Range (In. WC)
0 to 3
Accuracy
+/-2% of Full Scale
Output
4 to 20mA DC
Power Required
10 to 35V DC (2 Wire), 12 to 26V AC (4 Wire)
Process Connection Type
Hose Barb
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
616KD-02
Zoro #
G5475224
UPC #
-
Country of Origin
United States

Dimensions

Process Connection Size
1/8 in, 1/4 in
Process Connection Size - Transmitter
1/8 in
Overall Length
1.03 in
Overall Width
2.4 in

Details

Item
Differential Transmitter
Pressure Range (In. WC)
0 to 3
Accuracy
+/-2% of Full Scale
Output
4 to 20mA DC
Power Required
10 to 35V DC (2 Wire), 12 to 26V AC (4 Wire)
Process Connection Type
Hose Barb
Operating Temp. - Transmitter
0 Degrees to 140 Degrees F
Series
616KD
Standards
CE, UL Listed
Loop Resistance
DC at 1000 ohms Max, AC at 1200 ohms Max
Includes
Instruction Manual
Process Connection Type - Transmitter
Hose Barb
Range Values - Transmitter
0 to 3
Output Accuracy
+/-2% Full Scale
Range Units - Transmitter
in wc
Power Required - Transmitters
16 to 35V DC
Electrical Connections - Transmitter
Screw Terminals
Output - Transmitter
4 to 20mA DC
Accuracy - Transmitter
+/-2.00% Full Scale
Transmitter Type
Differential Transmitter
Connection
Barbed,Dual Size to Fit 1/8" and 3/16" (3 mm & 5 mm) ID Rubber or Vinyl Tubing
Wetted Materials - Transmitters
Stainless Steel
NEMA Rating
NEMA 1
Features
Push-Button Sets Back Zero and Span
Thermal Error
+/-0.06%
Wetted Materials
Stainless Steel
Electrical Connections
Screw Terminals
Maximum Loop Resistance
4 to 20 mA Output (DC): 1250 Ohm; 4 to 20 mA Output (AC): 1200 Ohm
NIST Traceable Certificate
No
Pressure Units
in wc
Minimum Pressure
0 in wc
Maximum Pressure
3 in wc
Overpressure
2 psig
Minimum Operating Temperature
0 Degrees F
IP Rating
IP20
Weight
1.8 oz
Process Connection Gender
Male
Number of Wires
2, 4
Maximum Operating Temperature
140 Degrees F
Pressure Measurement - Minimum
0 in wc
NEMA Enclosure Rating
1
Pressure Measurement - Maximum
3 in wc
Loop Resistance - Maximum
4 to 20 mA Output (DC): 1250 Ohm; 4 to 20 mA Output (AC): 1200 Ohm
Input Voltage
10 to 35V DC (2 Wire), 12 to 26V AC (4 Wire)
Process Media Temperature - Maximum
140 Degrees F
Includes NIST-Traceable Calibration Certificate
No NIST-Traceable Calibration Certificate Included
Output Power
4 to 20mA DC
Process Media Temperature - Minimum
0 Degrees F

Description

Differential Transmitter, Output 4 to 20mA DC, Minimum Pressure 0 in wc, Maximum Pressure 3 in wc, Overpressure 2 psig, Accuracy +/-2 Percent of Full Scale, Number of Wires 2, 4, Process Connection Gender Male, Process Connection Size 1/8 in, 1/4 in, Process Connection Type Hose Barb, Power Required 10 to 35V DC (2 Wire), 12 to 26V AC (4 Wire), IP Rating IP20, NEMA Rating NEMA 1, Series 616KD, Electrical Connections Screw Terminals, Burst Pressure Not Applicable
