Differential pressure transmitter, range 0-.25" w.c., NEMA 4X housing, with LCD display.
Mfr # 616WL-2-LCD
Zoro # G4604050
product price:Â
$
846.99
/ea
Free Shipping & Returns
Key Features
Accuracy
+/-0.50% of Full Scale
Output
4 to 20mA DC
Power Required
12 to 30V DC
Process Connection Type
Hose Barb
Process Connection Size
1/8 in, 3/16 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 616WL-2-LCD
- Zoro #
- G4604050
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Process Connection Size
- 1/8 in, 3/16 in
- Overall Width
- 3.703 in
- Overall Length
- 2.578 in
- Overall Height
- 5.125 in
- Housing Height
- 5 1/8 in
- Housing Length
- 3 11/16 in
- Manufacturer Warranty Length
- 1 yr
- Wire Rope Length
- 2.578 in
- Length
- 2.578 in
Description
Indicating Differential Transmitter, Output 4 to 20mA DC, Maximum Pressure 0.25 in wc, Minimum Pressure 0 in wc, Overpressure 2 psig, Accuracy +/-0.50 Percent of Full Scale, Number of Wires 2, Power Required 12 to 30V DC, Process Connection Size 1/8 in, 3/16 in, Process Connection Type Hose Barb, IP Rating IP66, NEMA Rating NEMA 4X, Series 616WL, Electrical Connections Screw Terminals, NIST Traceable Certificate No, Display Type Digital, Housing Material Plastic
