Shop DWYER INSTRUMENTS

Digital Pressure Transmitter, 5 in wc

  • Mfr # DM-008
  • Zoro # G007143554
product price:
$
171.99
/ea
Free Shipping & Returns

Key Features

Height
3 in
Sensor Length - Submersible Transmitter
5.7 in
Width
5.7 in
Weight
0.53 lbs
NEMA Enclosure Rating
4X
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
DM-008
Zoro #
G007143554
UPC #
-
Country of Origin
United States
Weight
0.53 lbs
NEMA Enclosure Rating
4X
Pressure Measurement - Maximum
5 in wc
Process Media Temperature - Maximum
158 Degrees F
Process Connection Location
Side
Item
Digital Pressure Transmitter
Pressure Measurement - Minimum
0 in wc
Thermal Error
0.02% Degrees F
Response Time
0 sec, 4 sec
Process Media Temperature - Minimum
-4 Degrees F
Burst Pressure
6 psi
Electrical Connection
Screw Terminals
Input Voltage
10 to 35V DC
Process Connection Type
Hose Barb
Accuracy
+/-1.00% of Full Scale
Housing Material
Plastic
Standards
CE
Loop Resistance - Maximum
1250 Ohm
Display Type
Digital
Output Power
4 to 20mA
IP Rating
IP66
Display Units
in wc
Digital Display Screen Type
LCD
Number of Wires
2
Series
Series DM
Features
Fast and Easy Setup and Calibration with Push-button Zero and Span Controls, Reduced Installation Time Through Zero and Span Controls that Provides Quick and Easy Calibration, Reduces Upgrade Installation Costs and Simplifies Field Upgrade from a Magnehelic Gage, as Both use the Same Diameter Cutout

Description

Digital Pressure Transmitter, Output 4 to 20mA, Maximum Pressure 6 psi, Accuracy +/-1.00 Percent of Full Scale, Number of Wires 2, Power Required 10 to 35V DC, Process Connection Size 1/8 in, 3/16 in, 5 mm, 6 mm, 1/4 in, Process Connection Type Hose Barb, IP Rating IP66, NEMA Rating NEMA 4X, Series Series DM, Wiring Entry Control Loop, Electrical Connections Screw Terminals, Display Type Digital, Housing Material Plastic, Burst Pressure 6 psi, Connection Location Side, Diameter 5 in
