Shop DWYER INSTRUMENTS

Handheld digital manometer, range 0-20.00 psi (1.379 bar), max. pressure 60 psig.

  • Mfr # 475-5-FM

  • Zoro # G3304537

product price:
$
326.99
/ea
Free Shipping & Returns

Key Features

Includes
9V Alkaline Battery
Standards
CE, FM Approved
Pressure Accuracy
+/-0.5%
Battery Type
9V
Pressure Resolution
0.01 psi
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
475-5-FM
Zoro #
G3304537
UPC #
-
Country of Origin
United States
Item
Handheld Digital Manometer
Includes
9V Alkaline Battery
Standards
CE, FM Approved
Pressure Accuracy
+/-0.5%
Battery Type
9V
Pressure Resolution
0.01 psi
For Use With
Boilers and Other Combustion Equipment, HVAC Systems
Calibration Certificate Included
No
Connection Type
Hose Barb
Application
Air; Natural Gas
Weight
0.675 lb
Process Connection Type
Hose Barb
Storage Temperature Range
-4 Degrees to 176 Degrees F
Auto Power Off
Yes
Number of Connections
2
Intrinsically Safe
Yes
Maximum Pressure
20 psi
Minimum Operating Temperature
0 Degrees F
Includes Batteries
Batteries Included
Number of Pressures Measured
Dual, Single
Digital Display Features
4 Digit LCD
Operating Pressure Range
0 to 20 psi
Maximum Operating Pressure
60 psig
Pressure Units
psig
Type of Pressure
Differential
Maximum Operating Temperature
140 Degrees F
Minimum Pressure
0 psi
NIST Traceable Certificate
No
Batteries Required
Yes
Housing Material
Aluminum
Low Battery Indicator
Yes
Zero Button
Yes
Safety Rating
Class I Div. 2 Group A, B, C, D
Series
475
Air Velocity Accuracy
+/-0.5% Full Scale from 60 to 78 Degrees F, +/-1.5% Full Scale from 32 to 60 Degrees F and 78 to 104 Degrees F
Maximum Storage Temperature
176 Degrees F
Minimum Storage Temperature
-4 Degrees F
Temperature Units
Degrees C, Degrees F
Pressure Type Measured
Differential
Operating Temperature - Maximum
140 Degrees F
Number of Process Connections
2
Pressure Stages Measured
Dual, Single
Includes NIST-Traceable Calibration Certificate
No NIST-Traceable Calibration Certificate Included
Includes Low Battery Indicator
Low Battery Indicator
Digital Display Type
LCD
Pressure Measurement - Minimum
0 psi
Pressure Measurement - Maximum
20 psi
Operating Temperature - Minimum
0 Degrees F
Number of Digits
4
Intrinsic Safety
Intrinsically Safe

Description

Handheld Digital Manometer, Maximum Pressure 20 psi, Minimum Pressure 0 psi, Pressure Accuracy +/-0.5 Percent, Process Connection Size 1/8 in, 3/16 in, Process Connection Type Hose Barb, Includes Batteries Batteries Included, Digital Display Features 4 Digit LCD, NIST Traceable Certificate No, Series 475, Pressure Units psig, Air Velocity Accuracy +/-0.5 Percent Full Scale from 60 to 78 Degrees F, +/-1.5 Percent Full Scale from 32 to 60 Degrees F and 78 to 104 Degrees F
