  13. Pressure Switch, SPDT, 1/8" MNPT, 0 to 2.0 in H2O Range
Dwyer Instruments Pressure Switch, SPDT, 1/8" MNPT, 0 to 2.0 in H2O Range MP-002 - main

Pressure Switch, SPDT, 1/8" MNPT, 0 to 2.0 in H2O Range

  • Mfr # MP-002

  • Zoro # G007143387

product price: $603.99
/ea
Free Shipping & Returns

Key Features

Contact Form
SPDT
Pressure Connection Type
1/8" MNPT
Range
0 to 2.0 in H2O
Standards
CE, cULus
Size
4-1/8" (104.78 mm) depth x 3-1/16" (77.79 mm) diameter.
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
MP-002
Zoro #
G007143387
UPC #
-
Country of Origin
United States

Dimensions

Size
4-1/8" (104.78 mm) depth x 3-1/16" (77.79 mm) diameter.

Details

Item
Pressure Switch
Contact Form
SPDT
Pressure Connection Type
1/8" MNPT
Range
0 to 2.0 in H2O
Standards
CE, cULus
Accuracy
±5% FS @ 70°F (21.1°C). Gage face mounted in vertical position.
Features
Gage reading unaffected by switch operation and will continue to read pressure even during power loss; Visible switch status LED provides indication of set point switching state; Compact design but with the power of larger devices can meet the same application specifications
Standard Accessories
(2) mounting screws, (1) .050" hex allen wrench.
Switch Type
(2) SPDT relays.
Mounting Orientation
Gage face in vertical position.
Temperature Limits
20 to 120°F (-6.7 to 49°C).
Service
Air and non-combustible, compatible gases.
Agency Approvals
CE, cULus.
Set Point Adjustment
Push buttons.
Power Requirements
24 VDC / 24 VAC 50/60 Hz 4 W.
Process Connections
Barbed for 3/16" ID tubing (STD); 1/8" male NPT (optional).
Pressure Limits
30 psig (2.067 bar).

Description

Differential pressure switch/gage, range 0-2.0" water.
