Shop DWYER INSTRUMENTS

Pressure Switch, SPDT, 1/8" NPT, 0 to 60 Pa Range

  • Mfr # 3000MR-60PA
  • Zoro # G207143408

product price:
$
750.99
/ea
Free Shipping & Returns

Key Features

Contact Form
SPDT
Pressure Connection Type
1/8 in NPT
Range
0 Pa to 60 Pa
Standards
CE
Features
Gage reading unaffected by switch operation and will continue to read pressure even during power loss; Zero and range adjustments outside of gage means no disassembly in normal service; Solid-state design allows for switching in high cycle rate applications without degradation
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
3000MR-60PA
Zoro #
G207143408
UPC #
-
Country of Origin
United States
Item
Pressure Switch
Contact Form
SPDT
Pressure Connection Type
1/8 in NPT
Range
0 Pa to 60 Pa
Standards
CE
Features
Gage reading unaffected by switch operation and will continue to read pressure even during power loss; Zero and range adjustments outside of gage means no disassembly in normal service; Solid-state design allows for switching in high cycle rate applications without degradation
Accuracy
±2% of FS (3000-0 ±3% of FS). (3000-00 ±4% of FS).
Switching Voltage
20-280 VAC (47-63 Hz).
Relay Contacts
(Resistive load) 1 form C rated 1.0A @ 30 VDC, 0.3A @ 110 VDC or 0.5A @ 125 VAC. Gold over clad silver - suitable for dry circuits.
Process Connections
1/8" female NPT (duplicated side and back).
Agency Approvals
CE.
Temperature Limits
20 to 120°F (-6.67 to 48.9°C).
Service
Air and non-combustible, compatible gases.
Switch Type
Each setpoint has 1 form C relays (SPDT).
Switching Current
1.0 amp (AC) max., 0.01 mA (AC) min., (2) SPST NO.
Power Requirements
24 VDC, regulated ±10%.
Pressure Limit
-20" Hg. to 25 psig (-0.677 bar to 1.72 bar). MP option: 35 psig (2.41 bar), HP option: 80 psig (5.52 bar).
Set Point Adjustment
Adjustable knobs on face.
Mounting Orientation
Diaphragm in vertical position. Consult factory for other position orientations.

Dimensions

Size
4" (101.6 mm) dial face, 5" (127 mm) OD x 3-1/8" (79.38 mm).

Description

Pressure switch/gage, range 0-60 Pa, 2.0 minor divisions.
