Shop DWYER INSTRUMENTS

Pressure Switch, Standard, SPDT, 1/8" FNPT, 0.4 to 1.6 in H2O Range

  • Mfr # 1950G-1-B-120-NA

  • Zoro # G707143434

product price:  $630.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
.4-1.6" w.c.
Factory On Setting
0.4"wc
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
1950G-1-B-120-NA
Zoro #
G707143434
UPC #
-
Country of Origin
United States

Details

Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
.4-1.6" w.c.
Factory On Setting
0.4"wc
Factory Off Setting
1.6"wc
Standards
ATEX, CE, CSA, FM, IECEx, UL
Features
Compatible with natural gas; External set point screw provides easy access that simplifies making adjustments without opening or disassembling enclosure; Easily accessible electrical connection simplifies the installation
Set Point Adjustment
Screw type on top of housing.
Agency Approvals
ATEX, CE, CSA, FM, IECEx, UL.
Mounting Orientation
Diaphragm in vertical position. Consult factory for other position orientations.
Service
Air and compatible combustible gases.
Temperature Limits
0 to 140°F (-17 to 60°C). Note: Set point drift may occur with ambient temperature changes.
Process Connections
1/8" female NPT.
Switch Type
1 Form C relay (SPDT).
Power Requirements
24 VDC ±10%. 120 or 240 VAC ±10% optional.
Pressure Limits
45" w.c. (11.2 kPa) continuous; 10 psig (68.95 kPa) surge.
