Pressure Switch, Standard, 2SPDT, 1/8" MNPT, 0 to 0.5 in H2O Range
- Mfr # MP-000
- Zoro # G3219791
product price:Â
$
562.99
/ea
Free Shipping & Returns
Key Features
Action
Standard
Contact Form
2SPDT
Pressure Connection Type
1/8 in MNPT
Range
0-0.5" water
Factory On Setting
0"wc
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- MP-000
- Zoro #
- G3219791
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Size
- 4-1/8" (104.78 mm) depth x 3-1/16" (77.79 mm) diameter.
Details
- Item
- Pressure Switch
- Action
- Standard
- Contact Form
- 2SPDT
- Pressure Connection Type
- 1/8 in MNPT
- Range
- 0-0.5" water
- Factory On Setting
- 0"wc
- Factory Off Setting
- 0.5"wc
- Standards
- CE, cULus
- Features
- Gage reading unaffected by switch operation and will continue to read pressure even during power loss; Visible switch status LED provides indication of set point switching state; Compact design but with the power of larger devices can meet the same application specifications
- Electrical Connection
- Screw type terminal block. Accepts 22-12 AWG wire.
- Process Connection
- Barbed for 3/16" ID tubing (STD); 1/8" male NPT (optional).
- Accuracy
- ±5% FS @ 70°F (21.1°C). Gage face mounted in vertical position.
- Mounting Orientation
- Gage face in vertical position.
- Temperature Limits
- 20 to 120°F (-6.7 to 49°C).
- Service
- Air and non-combustible, compatible gases.
- Switch Type
- (2) SPDT relays.
- Agency Approvals
- CE, cULus.
- Set Point Adjustment
- Push buttons.
- Power Requirements
- 24 VDC / 24 VAC 50/60 Hz 4 W.
Description
Differential Pressure Switch/Gage 0-05
