Shop DWYER INSTRUMENTS

Pressure Switch, Standard, SPDT, 1/2" NPT, 0.08 to 1.20 in H2O Range

  • Mfr # EDPS-08-1-N

  • Zoro # G0562707

product price:
$
41.79
/ea

Key Features

Action
Standard
Contact Form
SPDT
Pressure Connection Type
5/16" Barbed
Range
.08-1.20" w.c.
Housing Material
Nylon
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
EDPS-08-1-N
Zoro #
G0562707
UPC #
-
Country of Origin
Germany

Dimensions

Sample Line Connection Size
5/16 in

Details

Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Pressure Connection Type
5/16" Barbed
Range
.08-1.20" w.c.
Housing Material
Nylon
Factory On Setting
0.08"wc
Factory Off Setting
1.2"wc
Standards
CE, ETL approved to UL508 and CSA C22.2#14
Wetted Materials
ADPS: Diaphragm material: Silicone; Housing material: POM; Switch body: PA 6.6; Cover: Polystyrene; EDPS: Diaphragm material: Silicone; Housing material: Switch body: PA 6.6; Cover: Polystyrene; Materials UL 94 V-0 rated.
Process Connection
5/16" (7.94 mm) outside diameter tubing, 1/4" (6.0 mm) inside diameter tubing.
Features
Adjustment knob changes switching pressure easily with a pressure gage reducing components for application; Low cost device makes it an excellent solution in BAS and HVAC applications requiring duct control and monitoring; Relay contact allows simple integration with DDC or building systems
Electrical Connection
Push-on screw terminals. M20x1.5 with cable strain relief or optional 1/2" NPT connection.
Agency Approvals
CE, ETL approved to UL508 and CSA C22.2#14 (EDPS only).
Temperature Limits
Process and ambient temperature from -4 to 185°F (-20 to 85°C).
Mechanical Working Life
Over 106 switching operations.
Mounting Orientation
Vertical
Service
Air and non-combustible, compatible gases.
Switch Type
Single-pole double-throw (SPDT).
Pressure Type
Differential
Housing Type
Standard Housing
Reset Type
Automatic Reset
Number of Switches
1
Minimum Differential Pressure Setting
0.08 in wc
Minimum Operating Temperature
-4 Degrees F
Sample Line Connector Type
Barb
Maximum Operating Temperature
185 Degrees F
Maximum Differential Pressure Setting
1.2 in wc
Minimum Pressure Setting
0.08 in wc
Input Voltage
120/240V AC
Maximum Pressure Setting
1.2 in wc

Description

Pressure Switch, Contact Form SPDT, Housing Type Standard Housing, Input Voltage 120/240V AC, Maximum Differential Pressure Setting 1.2 in wc, Maximum Operating Temperature 185 Degrees F, Maximum Pressure Setting 1.2 in wc, Minimum Differential Pressure Setting 0.08 in wc, Minimum Operating Temperature -4 Degrees F, Minimum Pressure Setting 0.08 in wc, Mounting Orientation Vertical, Number of Switches 1, Pressure Type Differential, Reset Type Automatic Reset, Sample Line Connection Size 5/16 in
