Pressure Switch, Standard, SPDT, 1/8" FNPT, 0.01 to 0.2 in H2O Range
Mfr # 1640-0
Zoro # G0800987
product price:Â $793.99
/ea
Free Shipping & Returns
Key Features
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
.01-0.2" w.c.
Factory On Setting
0.01"wc
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
1640-0
Zoro #
G0800987
UPC #
-
Country of Origin
United States
Dimensions
Mounting Hole Diameter
0.28 in
Details
Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
.01-0.2" w.c.
Factory On Setting
0.01"wc
Factory Off Setting
0.2"wc
Standards
CE
Series
1640
Features
Floating “null†switch supports applications requiring two set point actions such as open and close damper control; Visible set point indicator simplifies operation and trouble shooting; Large diaphragm provides low range accuracy providing precise control
Electrical Connection
3 screw type, common, normally open and normally closed.
Process Connection
1/8" female NPT.
Set Point Adjustment
Screw type.
Temperature Limits
-30 to 110°F (-34.4 to 43.3°C).
Service
Air and non-combustible, compatible gases.
Agency Approvals
CE.
Switch Type
SPDT.
Mounting Orientation
Diaphragm in vertical position. Consult factory for other position orientations.
Mounting Hole Vertical Center to Center Distance
76 mm
Number of Mounting Holes
4
Mounting Hole Horizontal Center to Center Distance
51 mm
Description
Limit Switch, Series 1640
