  13. Pressure Switch, Standard, SPDT, 1/8" FNPT, 0.4 to 1.6 in H2O Range
Dwyer Instruments Pressure Switch, Standard, SPDT, 1/8" FNPT, 0.4 to 1.6 in H2O Range 1950G-1-B-24-NA - main

Pressure Switch, Standard, SPDT, 1/8" FNPT, 0.4 to 1.6 in H2O Range

  • Mfr # 1950G-1-B-24-NA

  • Zoro # G207143446

product price: $620.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8" FNPT
Range
0.4 to 1.6 in H2O
Standards
ATEX, CE, CSA, FM, IECEx, UL
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1950G-1-B-24-NA
Zoro #
G207143446
UPC #
-
Country of Origin
United States

Details

Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8" FNPT
Range
0.4 to 1.6 in H2O
Standards
ATEX, CE, CSA, FM, IECEx, UL
Features
Compatible with natural gas; External set point screw provides easy access that simplifies making adjustments without opening or disassembling enclosure; Easily accessible electrical connection simplifies the installation
Switch Type
1 Form C relay (SPDT).
Temperature Limits
0 to 140°F (-17 to 60°C). Note: Set point drift may occur with ambient temperature changes.
Service
Air and compatible combustible gases.
Pressure Limits
45" w.c. (11.2 kPa) continuous; 10 psig (68.95 kPa) surge.
Process Connections
1/8" female NPT.
Power Requirements
24 VDC ±10%. 120 or 240 VAC ±10% optional.
Set Point Adjustment
Screw type on top of housing.
Agency Approvals
ATEX, CE, CSA, FM, IECEx, UL.
Mounting Orientation
Diaphragm in vertical position. Consult factory for other position orientations.

Description

Explosion-proof differential pressure switch, range .4-1.6" w.c., approx. deadband @ min. set point .11, approx. deadband @ max. set point .29.
