Pressure Switch, Standard, SPDT, 1/8" FNPT, 3 to 11 in H2O Range
Mfr # 1950G-10-B-120-NA
Zoro # G007143455
product price: $654.99
/ea
Free Shipping & Returns
Key Features
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8" FNPT
Range
3 to 11 in H2O
Standards
ATEX, CE, CSA, FM, IECEx, UL
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
1950G-10-B-120-NA
Zoro #
G007143455
UPC #
-
Country of Origin
United States
Details
Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8" FNPT
Range
3 to 11 in H2O
Standards
ATEX, CE, CSA, FM, IECEx, UL
Features
Compatible with natural gas; External set point screw provides easy access that simplifies making adjustments without opening or disassembling enclosure; Easily accessible electrical connection simplifies the installation
Process Connections
1/8" female NPT.
Power Requirements
24 VDC ±10%. 120 or 240 VAC ±10% optional.
Mounting Orientation
Diaphragm in vertical position. Consult factory for other position orientations.
Service
Air and compatible combustible gases.
Pressure Limits
45" w.c. (11.2 kPa) continuous; 10 psig (68.95 kPa) surge.
Agency Approvals
ATEX, CE, CSA, FM, IECEx, UL.
Temperature Limits
0 to 140°F (-17 to 60°C). Note: Set point drift may occur with ambient temperature changes.
Switch Type
1 Form C relay (SPDT).
Set Point Adjustment
Screw type on top of housing.
