Pressure Switch, Standard, SPDT, 1/8" FNPT, 0.07 to .15 in H2O Range

  • Mfr # 1950G-00-B-120-NA
  • Zoro # G007143417
product price:
$
605.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
.07-.15" w.c.
Factory On Setting
0.07"wc
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
1950G-00-B-120-NA
Zoro #
G007143417
UPC #
-
Country of Origin
United States
Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
.07-.15" w.c.
Factory On Setting
0.07"wc
Factory Off Setting
0.15"wc
Standards
ATEX, CE, CSA, FM, IECEx, UL
Features
Compatible with natural gas; External set point screw provides easy access that simplifies making adjustments without opening or disassembling enclosure; Easily accessible electrical connection simplifies the installation
Service
Air and compatible combustible gases.
Pressure Limits
45" w.c. (11.2 kPa) continuous; 10 psig (68.95 kPa) surge.
Agency Approvals
ATEX, CE, CSA, FM, IECEx, UL.
Temperature Limits
0 to 140°F (-17 to 60°C). Note: Set point drift may occur with ambient temperature changes.
Process Connections
1/8" female NPT.
Set Point Adjustment
Screw type on top of housing.
Mounting Orientation
Vertical
Power Requirements
24 VDC ±10%. 120 or 240 VAC ±10% optional.
Switch Type
1 Form C relay (SPDT).
Maximum Pressure Rating
10 psig
Reset Type
Automatic Reset
Minimum Operating Temperature
0 Degrees F
Number of Switches
1
Pressure Type
Differential
Sample Line Connector Type
NPT
Maximum Operating Temperature
140 Degrees F
Maximum Differential Pressure Setting
0.15 in wc
Maximum Pressure Setting
0.06 in wc
Minimum Differential Pressure Setting
0.07 in wc
Input Voltage
120V AC
Minimum Pressure Setting
0.04 in wc
Housing Material
Aluminum
Electrical Connection Type
Screw Terminals
Weight
3.3 lb
Mounting Hole Center to Center Distance
4 7/8 in
Product Type
Pressure Switch
Pressure Setpoint Type
Adjustable
IP Rating
IP54
Housing Type
NEMA-3 Enclosure
Electrical Rating
10 A @ 120/240 V AC and 28 V DC, 50 mA Resistive @ 125 V DC

Dimensions

Mounting Hole Diameter
1/4 in
Overall Width
5 11/16 in
Overall Height
5 11/16 in
Sample Line Connection Size
1/8 in
Overall Depth
5 5/8 in

Description

Pressure Switch, Contact Form SPDT, Electrical Connection Type Screw Terminals, Electrical Rating 10 A @ 120/240 V AC and 28 V DC, 50 mA Resistive @ 125 V DC, Housing Material Aluminum, Housing Type NEMA-3 Enclosure, IP Rating IP54, Input Voltage 120V AC, Maximum Differential Pressure Setting 0.15 in wc, Maximum Operating Temperature 140 Degrees F, Maximum Pressure Rating 10 psig, Maximum Pressure Setting 0.06 in wc, Minimum Differential Pressure Setting 0.07 in wc
