  9. Pressure switch/gage, range 0-0.5" w.c., .01 minor divisions.
Dwyer Instruments Pressure switch/gage, range 0-0.5" w.c., .01 minor divisions. 3000MR-0 - main

Pressure switch/gage, range 0-0.5" w.c., .01 minor divisions.

  • Mfr # 3000MR-0

  • Zoro # G3268618

product price: $642.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-3%
Process Connection Type
NPT
Process Connection Size
1/8 in
Series
3000MR
Process Connection Gender
Female
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
3000MR-0
Zoro #
G3268618
UPC #
-
Country of Origin
United States

Dimensions

Process Connection Size
1/8 in
Nominal Dial Size
4 in
Bolt Circle Diameter
5.125 in
Case Diameter
5 in
Case Depth
2.5 in

Details

Item
Differential Gauge
Accuracy
+/-3%
Process Connection Type
NPT
Series
3000MR
Process Connection Gender
Female
Application
Air Conditioning Systems, Clean Rooms, Pneumatic Conveying
Process Connection Location
Back, Side
Pressure Range
0 to 0.5 in wc
Sensor Type
Diaphragm
Relay Type
SPDT
Standards
CE
Includes Calibration Certificate
No
Panel-Mountable
Yes
Compatible Process Media
Air, Non-Combustible Compatible Gases
Case Shape
Round
Mounting Orientation
Upright Only
Maximum Working Static Pressure
25 psig
Includes Mounting Hardware
Yes
Switch Contact Type
SPDT
Power Source
24V DC
Adjustable Set Points
Yes
Accuracy Details
+/-3% FS
Panel Mount Characteristics
(4) 6-32 Holes Equally Spaced on a 5-1/8 in Dia Bolt Circle
Switch Electrical Requirements
0.3A @ 110V DC/0.5A @ 125V AC; 1A @ 30V DC
Pressure Gauge Type
Differential Pressure Gauge with Switch
Ambient Operating Temperature Range
20 Degrees to 120 Degrees F
Operating Temperature - Minimum
20 Degrees F
Pressure Measurement - Minimum
0 in wc
Operating Temperature - Maximum
120 Degrees F
Pressure Measurement - Maximum
0.5 in wc
Switch Contact Form
SPDT
Working Static Pressure - Maximum
25 psig

Description

Differential Guage
