Eaton Current Sensing Rly, 1to150A, Self Powered ECSNCASC - main

Current Sensing Rly, 1to150A, Self Powered

  • Mfr # ECSNCASC

  • Zoro # G2596155

product price: $160.99
/ea
Free Shipping & Returns

Key Features

Input or Control Voltage
Self Powered
AC Contact Rating - Relay
0.20A @ 135V
DC Contact Rating - Relay
0.20A @ 135V
Mounting - Relay
Surface
Contact Form - Relay
SPST-NC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ECSNCASC
Zoro #
G2596155
UPC #
786685120959
Country of Origin
United States

Dimensions

Body Height - Relay
2.18 in
Body Width - Relay
3.5 in
Overall Height - Relay
2.18 in
Body Depth - Relay
0.93 in
Body Depth
2.18 in
Sensing Hole Diameter
0.74 in
Body Width
0.93 in
Body Height
2.3 in
Overall Depth
2.18 in
Product Length/Depth
2.18 in
Product Height
2.3 in
Product Width
.93 in

Details

Item
Adjustable Current Sensing Relay
Input or Control Voltage
Self Powered
AC Contact Rating - Relay
0.20A @ 135V
DC Contact Rating - Relay
0.20A @ 135V
Mounting - Relay
Surface
Contact Form - Relay
SPST-NC
Sensing Amp Range
1.00 to 150.00A
Trip Point
1 to 150 A
Trip Delay
0.12 sec
Core Type - Relay
Solid
Sensor Opening
0.74 in
Status Indicator
LED
Type of Output
Solid State
Input or Control Voltage Range
Self Powered
Contact Form
SPST-NC
Item - Relay
Current Sensing Relay
Core Type
Solid
Mounting
Surface
Electrical Connection
Screw Terminal
Max. Inrush Current
150 A
Contact Amps
0.20A
Minimum Operating Temperature
-58 Degrees F
Contact Rating (AC)
0.2 A @ 135V
Frequency
100 Hz
Wire Gauge
14 AWG
Monitored Parameters
Overcurrent, Undercurrent
For Use With
Sensors
Maximum Operating Temperature
122 Degrees F
Mounting Style
Surface
Weight
0.25 lb
Operating Current
0.2 A, 150 A
Current Rating
150 A
Standards
RoHS Compliant, UL Listed
Trip Point Type
Adjustable
Adjustment Method
Switch
Contact Rating (DC)
0.2 A @ 135V
Number of Pins
2
Housing Material
Plastic
Contact configuration
Isolated solid state relay
AC current - max
150 A monitor, 0.2 A switch
Connection
Screw terminal
LED indicator
Contact status: red LED
Enclosure material
UL94 V0 flammability rated plastic
Operating Temperature
-58° to 122°F (-50° to 50°C)
Switch type
Current switch
Contact Rating
0.2A at 135 Vac/DC
Product Name
Eaton ECS series CurrentWatch AC current switch

Description

Adjustable Current Sensing Relay, Contact Form SPST-NC, Contact Rating (AC) 0.2 A @ 135V, Contact Rating (DC) 0.2 A @ 135V, Core Type Solid, Current Rating 150 A, Input Voltage Not Applicable, Monitored Parameters Overcurrent, Undercurrent, Mounting Style Surface, Number of Pins 2, Trip Point 1 to 150 A, Trip Point Type Adjustable, Adjustment Method Switch, Electrical Connection Screw Terminal, Sensing Hole Diameter 0.74 in, Wire Gauge 14 AWG, Body Depth 2.18 in, Body Height 2.3 in
