Eaton Cutler-Hammer Circuit Breaker, BD Series, 15A, 1 Pole, 120V AC, 10kA BD1515 - main

Circuit Breaker, BD Series, 15A, 1 Pole, 120V AC, 10kA

  • Mfr # BD1515

  • Zoro # G2702214

CAD Available
product price:  $22.25
/ea

Key Features

CAD Drawing
Series
BD
Number of Poles
1
AC Voltage Rating
120V AC
Circuit Breaker Mounting Style
Plug In
Max. AIR Rating
10kA
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
BD1515
Zoro #
G2702214
UPC #
786676369053
Country of Origin
Dominican Republic

Dimensions

Width
1 in
Depth
2.90 in
Height
2-1/2 in
Max. Wire Size
4 AWG (Cu/Al)
Min. Wire Size
14 AWG (Cu/Al)
Wire Size
#14-4 AWG Cu/Al
Frame Size
BR

Details

Item
Circuit Breaker
Series
BD
Amps
15A
Number of Poles
1
AC Voltage Rating
120V AC
Circuit Breaker Mounting Style
Plug In
Max. AIR Rating
10kA
Trip Type
Thermal Magnetic
DC Voltage Rating
Not Rated
For Use With
Type BR Loadcenters
Interrupt Rating
10 kA
Features
Rejection Tab Feature
Certifications
UL 489
Special Features
Includes rejection tab feature
Compliances
Federal Specifications Classification W-C375
CAD Available
Yes
Circuit Breaker Type
Tandem

Description

Circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). The Eaton cutler-hammer 15/15 amp 1 inch duplex type BD circuit breaker is also known as tandem or circuit limiting breaker. This style of breaker will only fit into load center bus stabs that are notched to accommodate the rejection clip built into the bus bar contact on the breaker. This is a code requirement that limits the number of breakers that can be installed into a load center.


  • • Twin 15/15
  • • Heating and AC Rated (HACR)
  • • Circuit Limiting for notched bus bars
  • • Switching Duty Rated
  • • 1" Format
  • • 1" Format
