Combination Circuit Breaker, BR Series, 20A, 1 Pole, 120V AC, 10kA
Mfr # BRP120AF
Zoro # G104257819
product price:Â $99.55
/eaKey Features
Series
BR
Amps
20 A
Number of Poles
1
AC Voltage Rating
120V AC
Circuit Breaker Type
AFCI Combination
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- BRP120AF
- Zoro #
- G104257819
- UPC #
- 786689041021
- Country of Origin
- United States
Dimensions
- Width
- 3-1/2 in
- Depth
- 6 in
- Height
- 1-1/8 in
- Max. Wire Size
- 8 AWG (Cu/Al)
- Min. Wire Size
- 14 AWG (Cu/Al)
Details
- Item
- Combination Circuit Breaker
- Series
- BR
- Amps
- 20 A
- Number of Poles
- 1
- AC Voltage Rating
- 120V AC
- Circuit Breaker Type
- AFCI Combination
- Circuit Breaker Mounting Style
- Plug In
- Max. AIR Rating
- 10kA
- Terminal Connection
- Plug-On
- DC Voltage Rating
- Not Rated
- Standards
- UL Listed
- For Use With
- Type BR Loadcenters
- Interrupt Rating
- 10 kA
Description
Plug-on combination type arc fault circuit breakers, 10,000 A interrupting capacity. Combination type arc fault circuit interrupter includes all of the protection offered by the branch feeder AFCI (mitigation of parallel arcing faults in the complete circuit, including connected cords). In addition it provides direct detection of persistent low current arcing faults down to 5 A with associated mitigation of fire hazards in the cords connected to the outlets. Parallel arcing faults can occur from line to neutral or line to ground. These arcing faults are in parallel with the load and produce the most energy of all arcing faults. The current level of low current arcing faults is limited by the load.
