  15. Cutler-Hammer Limit Switch Head, Push Roller Plungr, Top
Eaton Cutler-Hammer Limit Switch Head, Push Roller Plungr, Top E50DT3 - main

Cutler-Hammer Limit Switch Head, Push Roller Plungr, Top

  • Mfr # E50DT3

  • Zoro # G5232001

product price: $201.99
/ea
Free Shipping & Returns

Key Features

Actuator Style
Push Roller Plunger
Actuator Location
Top
Actuator Length
1.1 in
For Use With
Mfr. No. E50SA
NEMA Rating
1, 12, 13, 2, 4, 4X, 6P
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
E50DT3
Zoro #
G5232001
UPC #
782113290614
Country of Origin
Mexico

Dimensions

Actuator Length
1.1 in
Product Width
1.54 in
Product Length/Depth
1.88 in
Product Height
1.78 in
Manufacturer Warranty Length
1 yr
Overall Height
1.78 in
Roller Width
0.16 in
Roller Diameter
0.44 in
Overall Width
1.54 in
Arm Length - Maximum
1.1 in
Overall Depth
1.88 in

Details

Item
Limit Switch Head
Actuator Style
Push Roller Plunger
Actuator Location
Top
For Use With
Mfr. No. E50SA
NEMA Rating
1, 12, 13, 2, 4, 4X, 6P
Movement
Top
Operating Force
2.2 N
IP Rating
IP67
Voltage Rating
600V AC
Amps
10
Travel
Operating Travel 0.04 in, Reset Travel 0.02 in, Total Travel 0.28 in
Description/Special Features
Momentary
Standards
CSA, RoHS, UL Listed
Operating Temp.
14 Degrees to 221 Degrees F
Actuator
Top push roller
Environmental rating
NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
Enclosure material
Die cast zinc
Operating temperature - max
201°F
Series
E50
Operating temperature - min
14°F
Certifications
CSA Certified
Product Name
Eaton E50 NEMA heavy duty plug-in limit switch
Compatible with Manufacturer Model Number
E50SA
Roller Material
Nylon
NEMA Enclosure Rating
1, 13, 3, 3S, 4, 4X, 6, 6P
Roller Position
Side
Differential Travel
0.28 in
Action
Momentary
Directional Movement
Linear
Overtravel
0.04 in
Compatible with Series
E50
Operating Torque
4 in-lb
Operating Temperature - Minimum
14 Degrees F
Total Travel
0.28 in
Plunger Adjustability
Fixed
Reset Travel
0.02 in
Operating Temperature - Maximum
201 Degrees F
Compatible with Brand
Eaton
Roller Adjustability
Fixed
Pretravel
0.02 in
Includes Actuator
Actuator Included
Compatible Manufacturer Part Number
E50SA
Compatible Manufacturer Model Number
E50SA
Compatible with Manufacturer Model No.
E50SA
Compatible with Mfr. Model No.
E50SA
For Use with Mfr Model Number
E50SA
For Use With Mfr. Model Number
E50SA
Compatible Pump Manufacturer Part Number
E50SA
Compatible Mfr. Model Number
E50SA

Description

Limit Switch Head, Actuator Style Push Roller Plunger, Actuator Location Top, Actuator Length 1.1 in, Contact Form Not Applicable, Amps 10, Voltage Rating 600V AC, Travel Operating Travel 0.04 in, Reset Travel 0.02 in, Total Travel 0.28 in, Movement Top, Operating Force 2.2 N, Operating Temp. 14 Degrees to 221 Degrees F, NEMA Rating 1, 12, 13, 2, 4, 4X, 6P, IP Rating IP67, Standards CSA, RoHS, UL Listed, For Use With Mfr. No. E50SA
