Eaton DC Power Supply, 24V DC, 24V DC, 480 W, 2.5 A, DIN Rail PSG480B24RM - main

DC Power Supply, 24V DC, 24V DC, 480 W, 2.5 A, DIN Rail

  • Mfr # PSG480B24RM

  • Zoro # G8569416

product price: $513.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
24V DC
Output Voltage - Nominal
24V DC
Output Power - Rated
480 W
Current - Output
2.5 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PSG480B24RM
Zoro #
G8569416
UPC #
-
Country of Origin
Thailand

Dimensions

Overall Height
1.97 in
Overall Width
4.8 in
Overall Depth
4.76 in
Height
4.8 in
Depth
4.76 in
Width
1.97 in

Details

Item
DC Power Supply
Input Voltage
24V DC
Output Voltage - Nominal
24V DC
Output Power - Rated
480 W
Current - Output
2.5 A
Mounting
DIN Rail
Housing Material
Aluminum
Phase
Single
Power Supply Style
Switching
Hold Up Time
Greater Than 22 msec
Output Voltage
24V DC
Output Amps
20A
Style
Switching
Peak Amps
20
IP Rating
IP20
Hz
50/60 Hz
Power Rating
480W
Phase - Electrical
Single
Series
PSG
Case Material
Aluminum Case
Status Indicator
LED/DC OK Signal
Features
Din Rail Mounting, Industrial Power Supply, Low Output Noise, Overvoltage And Short Circuit Protection, Screw Terminal Connections, Ultra Slim Footprint
Output Noise
Less Than 50mV
Operating Temp. Range
-20 to 80°C
Standards
CE, CSA, cUL 62368-1, cULus/UL 60950-1, DIN 57100-410, EN 50178, EN 60204, EN 61000-4-11, EN 61000-4-2, EN 61000-406, EN 61000-6-2, EN 61000-6-3, EN 610003-2, German Safety, IEC, PELV (EN 60204), RoHS, SELV (EN 60950), UL 508, UL 62368-1
Degree Of Protection
IP20
Certifications
UL 508;CSA Certified;EN 61000-4-2;EN 61000-6-2;EN 61000-406;EN 61000-4-11;IEC Rated;EN 60204;PELV (EN 60204);EN 50178;EN 61000-6-4;cULus/UL 60950-1;SELV (EN 60950);EN 610003-2
Compliances
CE Marked;German Safety;DIN 57100-410
NEMA Enclosure Rating
1
Input Frequency - Nominal
50/60 Hz
Special Features
Overvoltage Protection
Operating Temperature - Maximum
167 Degrees F
Current - Inrush
20 A
Current - Peak
20 A
Operating Temperature - Minimum
-4 Degrees F

Description

DC Power Supply, Input Voltage 24 to 48V DC, Output Voltage 24V DC, Power Rating 480W, Output Amps 20, Mounting DIN Rail, Switching, Case Material Aluminum Case, Height 4.8 in, Width 1.97 in, Depth 4.76 in, Series PSG, Hz 50 to 60 Hz, Phase - Electrical Single, Peak Amps 20, IP Rating IP20, Output Noise Less Than 50mV, Hold Up Time Greater Than 22 msec, Status Indicator LED/DC OK Signal, NEMA Rating 1
