Shop EATON

Horn, Horn, Continuous/Pulse, 12V, 24V, 80 dBA, Plastic, White, Ceiling Mount

  • Mfr # ELHNRC

  • Zoro # G605987710

product price:
$
52.49
/ea

Key Features

Housing Material
Plastic
Mounting
Ceiling
Diameter
6.25 in
Color
White
Audible Alarm Type
Horn
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ELHNRC
Zoro #
G605987710
UPC #
786697009532
Country of Origin
Romania

Dimensions

Diameter
6.25 in
Height
1.8 in
Width
6.27 in
Overall Depth
1 5/16 in
Overall Diameter
6 1/4 in

Details

Item
Horn
Housing Material
Plastic
Mounting
Ceiling
Color
White
Audible Alarm Type
Horn
Voltage
12V, 24V
Standards
UL Listed, ULC Listed
Indoor/Outdoor
Indoor
Decibels
80 dBA
Sound Pattern
Continuous/Pulse
Features
Continuous T3 and T3/T4, Energy Efficient, Fire and CO Signaling in 1 Device, Low-Profile Design
Current Drawn
0.022 DC, 0.03 DC, 0.06 DC, 0.086 DC, 0.125 DC, 0.185 DC
Watts
5 W
Housing Color
White
Lamp Type
LED
Operating Temp.
32 Degrees to 122 Degrees F
Visual Indicator Type
No Visual Indicator
Includes
Mounting Plate
Lens Material
Lexan(R)
Material
Plastic
Product Type
Horn
Wattage
5 W
Includes Mounting Hardware
Mounting Hardware Included
Legend
no lettering
Alarm Volume @ 10 ft - Minimum
80 dBA
For Location
Indoor
Operating Current
0.086 A @ DC
Operating Temperature - Maximum
122 Degrees F
Mounting Style
Surface Mount
Operating Temperature - Minimum
32 Degrees F
Sound Style
Horn
Operating Voltage
12V, 24V

Description

The EATON ELHNRC is an indoor ceiling-mount horn for audible signaling. It produces an 80 dBA horn sound with continuous or pulse operation and is rated for 12V and 24V operation. The low-profile white plastic housing is designed for indoor ceiling-mount audible signaling applications.

Key Features:

  • Audible alarm type: Horn with continuous and pulse sound patterns.
  • Sound output: 80 dBA minimum at 10 ft.
  • Voltage: 12V, 24V.
  • Operating current: 0.086 A @ DC; listed current draw values: 0.022 DC, 0.03 DC, 0.06 DC, 0.086 DC, 0.125 DC, 0.185 DC.
  • Construction: White plastic housing with Lexan® lens material.
  • Mounting: Surface mount for ceiling installation; mounting plate and mounting hardware included.
  • Design features: Low-profile design; power rating: 5 W; includes continuous T3 and T3/T4 temporal sound patterns.
  • Operating temperature: 32°F to 122°F.
  • Dimensions: 6.25 in. diameter, 1.8 in. height, 6.27 in. width, 1 5/16 in. overall depth.
  • Location rating: Indoor.
  • Standards: UL Listed, ULC Listed.
  • Visual indicator type: No visual indicator.
