Eaton Illuminated Button w/Contacts, 120VAC 10250T853RD2A - main

Illuminated Button w/Contacts, 120VAC

  • Mfr # 10250T853RD2A

  • Zoro # G8737251

product price: $343.99
/ea
Free Shipping & Returns

Key Features

Voltage
120V AC
Color
Green
Action
Momentary/Momentary
Lamp Type
LED
Type of Operator
Mushroom Head Illuminated
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
10250T853RD2A
Zoro #
G8737251
UPC #
782114541531
Country of Origin
Dominican Republic

Dimensions

Size
30 mm
Length
1 in
Height
1 in
Width
1 in
Product Diameter
1.38 in
Manufacturer Warranty Length
1 yr
Overall Depth
1 in
Mushroom Head Diameter
40 mm
Overall Width
1 in
Panel Cutout Diameter
30 mm
Overall Height
1 in

Details

Item
Mushroom Head Push Button
Voltage
120V AC
Color
Green
Action
Momentary/Momentary
Lamp Type
LED
Type of Operator
Mushroom Head Illuminated
Head Material
Metal
Contact Form
1NO/1NC
Terminal Connection
Screw Clamp
Bezel
Epoxy Coated/Chemical Resistant Metal
Lamp Module Voltage
120V AC
Lamp Module Type
Full Voltage
NEMA Contact Rating Designation
A600 and Q300
Number of Operators
1
IP Rating
IP65
Contact Rating
10A @ 600V AC, 2.5A @ 250V DC
Safety Rating
Class 1, Div 2, Groups B,C, D (NEC), Class 1, Zone 2, IIB and H2 (NEC 505)
Standards
CE, CSA, FDA 3-A, UL 1604, UL 508
Lamp Voltage
120V AC
NEMA Rating
12, 13, 3, 3R, 4, 4X
Product Type
Push Button Operators
Type
Class I Division 2
Bus Material
Plastic
Lamp Voltage - Min
120 VAC
Light Unit Type
LED, full voltage
Contact Configuration
1 NO-1 NC
Lamp Voltage - Max
120 VAC
Light Unit Voltage
120 Vac
Series
10250T
Rating
NEMA 12;NEC Class I Division 2, Groups B, C and D;NEMA 4X;NEMA 3;NEMA 13;NEMA 4;NEMA 3R
Actuator
Standard
Certifications
CSA Certified;UL 508;UL 1604
Illumination
Illuminated
Number of Positions
2
Actuator Color
Red
Compliances
CE Marked;FDA 3-A
Product Name
Eaton 10250T pushbutton
Operating Mode
Pull: momentary;Push: momentary
Features
Factory Sealed, Drainage Holes, Grounding Nibs
Push Button Style
Mushroom Head
NEMA Enclosure Rating
12, 13, 3, 3R, 4, 4X
Head Color
Red
Operating Temperature - Minimum
32 Degrees F
Operating Temperature - Maximum
140 Degrees F
Operator Material
Metal
Operator Illumination
Illuminated
Mechanical Operating Durability
1.00 x 10^7
Lamp Voltage - Maximum
120 V AC
AC Contact Rating
10 A @ 600 V
Hazardous Location Specification
Class I, Div 2, Group B, C, D
DC Contact Rating
5 A @ 250 V
Resistance Properties
Oil and Grease Resistant
Bezel Material
Zinc Die Cast
Number of Indicator Lights
0

Description

Mushroom Head Push Button, 30 mm, Momentary/Momentary Action, Mushroom Head Illuminated Type of Operator, Head Material Metal, Contact Form 1NO/1NC, Bezel Epoxy Coated/Chemical Resistant Metal, Color Green, Contact Rating 10A @ 600V AC, 2.5A @ 250V DC, NEMA Contact Rating Designation A600 and Q300, Number of Operators 1, NEMA Rating 12, 13, 3, 3R, 4, 4X, IP Rating IP65, Standards CE, CSA, FDA 3-A, UL 1604, UL 508, Terminal Connection Screw Clamp
