Shop EATON

Load Center, CH, 4 Spaces, 125A, 120/240V AC, Main Lug, 1 Phase

  • Mfr # CH4L125RP

  • Zoro # G205305365

product price:
$
83.75
/ea

Key Features

Main Circuit Breaker or Main Lug
Main Lug
Number of Spaces
4
Amps
125 A
Voltage
120/240V AC
Phase
1
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
CH4L125RP
Zoro #
G205305365
UPC #
782114190517
Country of Origin
United States

Dimensions

Height
3.69 in
Width
11 in
Depth
13 in
Max. Wire Size
1/0 AWG
Min. Wire Size
#14

Details

Item
Load Center
Main Circuit Breaker or Main Lug
Main Lug
Number of Spaces
4
Amps
125 A
Voltage
120/240V AC
Phase
1
Short Circuit Current Rating
25kA
Series
CH
Enclosure Material
Metallic
Enclosure NEMA Rating
NEMA 3R
Bus Material
Copper
Weight
12 lb
Standards
UL 50
Special features
Standard
Number of wires
3
Number Of Poles
Eight-pole
Number Of Circuits
4
Feed type
Overhead

Description

Specially designed for easy installation, Eaton's CH load centers house the branch circuit breakers and the wiring required to distribute power to individual circuits. This panel is a main lug panel which is used as sub-panel to add circuits to an existing main breaker panel. Sub panels are often used in a garage, home addition, barn or storage shed and/or workshop. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets. The CH4L125RP is a 125 amp outdoor main lug with 4 spaces and 8 circuits.


  • • 125 amp
  • • 4 space type CH
  • • NEMA 3R Outdoor
  • •
  • •
