This item is Discontinued.

Eaton Soft Start, NEMA 1/IP20,600VAC S611C156N3S

Soft Start, NEMA 1/IP20,600VAC (Discontinued)

  • Mfr # S611C156N3S
  • Zoro # G9511966
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S611C156N3S
Zoro #
G9511966
UPC #
786685480343
Country of Origin
Dominican Republic

Dimensions

Width
11.58 in
Height
21.01 in
Depth
8.57 in
Overall Height
21.01 in
Overall Width
11.58 in
Overall Depth
8.57 in

Details

Output Current
156 A
Frequency
50/60 Hz
Phase
Three
Enclosure Rating
NEMA 1
Start Type
Exclusive Patented Intelligent Technology, Reduced Voltage Starting, Available with Kick Start, Torque Control or Current Limit
Application
Constant and Variable Torque
Protects
Advanced Motor Protection, Jam, Stall, Phase Loss, Phase Imbalance, Ability to Alarm Without Tripping for Critical Situations, Ability for Advance Communications for Critical Load Monitoring is Required
Standards
CSA 3211-06, IEC 60947-4-2, UL Listed
Stop Time
1 to 180 sec
Includes
IT Technology, Internal Bypass Contactors
Control Voltage
108 to 132V AC
Ramp Time
0.5 to 180 sec.
Display
Digital
HP @ 3 Phase - 575V
150 hp
Communication Port
Modbus Built-In, Ethernet IP, Profibus and Devicenet Available, Two Different Communication Ports Available
HP @ 3 Phase - 208V
50 hp
HP @ 3 Phase - 240V
60 hp
Output Voltage
600V AC
Inputs/Outputs
(3) 6A Relay Outputs
Input Voltage
600V AC
Starting Torque
0% to 83%
HP @ 3 Phase - 480V
125 hp
With Bypass / No Bypass
With Bypass
IP Rating
20
Item
Soft Start
HP @ 3 Phase - 230V
60 hp
HP @ 3 Phase - 460V
125 hp
Output Power
125 hp @ 3 Phase, 480V AC, 150 hp @ 3 Phase, 575V AC, 50 hp @ 3 Phase, 200V AC, 60 hp @ 3 Phase, 240V AC
Function Type
Start or Stop
Type
Digital Keypad Control

Description

Soft Start, Input Voltage 600V AC, Output Current 156 A, Output Voltage 600V AC, 125 hp @ 3 Phase, 480V AC, 150 hp @ 3 Phase, 575V AC, 50 hp @ 3 Phase, 200V AC, 60 hp @ 3 Phase, 240V AC, Control Voltage 108 to 132V AC, NEMA 1
