  11. Soft Starter, 180A, 0 to 600VAC, 3 Phase
Eaton Soft Starter, 180A, 0 to 600VAC, 3 Phase S611C180N3S - main

Soft Starter, 180A, 0 to 600VAC, 3 Phase

  • Mfr # S611C180N3S

  • Zoro # G0315990

product price: $4,018.99
/ea
Free Shipping & Returns

Key Features

HP @ 3 Phase - 480V
150 hp
Standards
CCC, CE, CSA, IEC 60947, UL
Starting Torque
0% to 83%
Width
11.58 in
IP Rating
20
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S611C180N3S
Zoro #
G0315990
UPC #
786685480350
Country of Origin
Dominican Republic

Dimensions

Width
11.58 in
Depth
8.57 in
Height
21.01 in
Overall Height
21.01 in
Overall Depth
8.57 in
Overall Width
11.58 in

Details

HP @ 3 Phase - 480V
150 hp
Standards
CCC, CE, CSA, IEC 60947, UL
Starting Torque
0% to 83%
IP Rating
20
Includes
IT Technology, Internal Bypass Contactors
Ramp Time
0.5 to 180 sec.
With Bypass / No Bypass
With Bypass
Protects
Advanced Motor Protection, Jam, Stall, Phase Loss, Phase Imbalance, Ability to Alarm Without Tripping for Critical Situations, Ability for Advance Communications for Critical Load Monitoring is Required
Enclosure Rating
NEMA 1
HP @ 3 Phase - 208V
60 hp
Output Current
180 A
Application
Constant and Variable Torque
Frequency
50/60 Hz
HP @ 3 Phase - 240V
60 hp
Start Type
Exclusive Patented Intelligent Technology, Reduced Voltage Starting, Available with Kick Start, Torque Control or Current Limit
Phase
Three
Item
Soft Start
Input Voltage
600V AC
Communication Port
Modbus Built-In, Ethernet IP, Profibus and Devicenet Available, Two Different Communication Ports Available
Inputs/Outputs
(3) 6A Relay Outputs
Output Voltage
600V AC
Stop Time
0 to 180 sec
Control Voltage
108 to 132V AC
HP @ 3 Phase - 575V
150 hp
HP @ 3 Phase - 230V
60 hp
HP @ 3 Phase - 460V
150 hp
Function Type
Start or Stop
Output Power
150 hp @ 3 Phase, 480V AC, 150 hp @ 3 Phase, 575V AC, 60 hp @ 3 Phase, 200V AC, 60 hp @ 3 Phase, 240V AC
Display
Digital
Type
Digital Keypad Control

Description

Soft Start, Input Voltage 600V AC, Output Current 180 A, Output Voltage 600V AC, 150 hp @ 3 Phase, 480V AC, 150 hp @ 3 Phase, 575V AC, 60 hp @ 3 Phase, 200V AC, 60 hp @ 3 Phase, 240V AC, Control Voltage 108 to 132V AC, NEMA 1
