Shop EATON WIRING DEVICES

Straight Blade Plug, 5-15P, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # 4867AN-SP

  • Zoro # G807387363

product price:  $14.19
/ea

Key Features

NEMA Plug Configuration
5-15P
Current Rating
Full Rated Current; 15 A
Voltage Rating
125V AC
Number of Poles
2
Wire Connection Type
Screw Terminals
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
4867AN-SP
Zoro #
G807387363
UPC #
32664752261
Country of Origin
United States

Dimensions

Height
5.5 IN
Width
4.25 IN
Wire Size
#18-12 AWG

Details

Item
Straight Blade Plug
NEMA Plug Configuration
5-15P
Current Rating
Full Rated Current; 15 A
Voltage Rating
125V AC
Number of Poles
2
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Grounding
Grounded
Housing Color
Yellow
IP Rating
IP66, IP67, IP69K
Standards
UL
Resistance Properties
Resists chemical attack
Special Features
Angled body
Material
Vinyl
Number of Wires
3
Application
Commercial
Wiring Method
Back wire
Cord Grip Range (in)
.234-.687
Number Of Wires
Three-wire
Blade Material
Nickel-Plated Brass
Environment
Wet
Body Material
EPTR Rubber; Vinyl
Dielectric Strength
Withstands 2000V per UL498
Temp. Rise
Max 30C after 250 cycles OL at 200 percent rated current
Housing Material
Santoprene TPV
Contact Material
Brass
Operating Temp.
-40°C to 60°C
Body Style
Angled body
Connection Type
Screw
Flammability
Rated V-2 per UL 94
Weight (Lbs.)
.098 LB

Description

Solid brass plug blades are firmly embedded in body Resists chemical attack and is less brittle in extremely low temperatures With terminal screw clamps Combination SlotPhillips head mounting and terminal screws for installation flexibility SlotRobertson screws in Canada where available Terminal screws backed out, ready for wiring Yellow color Meets all UL 498 requirements
