Horn Strobe, Horn, Pulse, 120VAC, 85 dB, Cast Aluminum, Green Lens, Gray Housing, Surface Mount
- Mfr # 51XBRFG120A
- Zoro # G6622016
product price:Â
$
420.99
/ea
Free Shipping & Returns
Key Features
Housing Material
Cast Aluminum
Mounting
Surface
Diameter
6 in
Audible Alarm Type
Horn
Standards
cUL, UL
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Description
EDWARDS SIGNALING 51XBRFG120A is a surface-mount horn strobe for audible and visual signaling in indoor and outdoor locations. It combines a pulsed horn with a flashing green LED beacon/strobe, operates on 120VAC, and uses a direct-wire connection through a conduit hole. The cast aluminum housing and polycarbonate Fresnel lens are components of a mounted signaling device.
Key Features:
- Audible and visual signaling with pulsed horn output and flashing LED light
- Sound output: 85 dB at 10 ft maximum; 95 dB at 1 m maximum
- Visual signal: flashing green LED light at 65 flashes per minute
- Surface-mount design with junction box base; mounting hardware included
- Cast aluminum housing with polycarbonate Fresnel lens
- Green lens with gray/silver housing
- Electrical: 120VAC operating voltage, 0.175 A operating current, direct-wire power source
- Connection: conduit hole
- Temperature range: -31 degrees F to 160 degrees F
- Rated lamp life: 148,000 hr
- Dimensions: 6 in diameter, 7 3/8 in overall depth, 7.375 in height, 6 in width
- Standards: cUL, UL
