Shop ELMO RIETSCHLE

Vacuum Pump, 1.5 kW, 16.5" W, 18 in Hg

  • Mfr # 1028950100-2H

  • Zoro # G805302184

product price:
$
8,645.99
/ea
Additional $110.00 delivery surcharge applies per item.
See details

Key Features

Voltage
230 / 400 V +/-10% (50 Hz), 265 / 460 V +/-10% (60 Hz)
Phase
Three
Weight
154 lb
Overall Length
27.8 in
Overall Width
16.5 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
1028950100-2H
Zoro #
G805302184
UPC #
-
Country of Origin
Germany

Dimensions

Overall Length
27.8 in
Overall Width
16.5 in
Overall Height
10.9 in
Inlet Size
1 1/2 in
Wire Rope Length
27.8 in
Length
27.8 in

Details

Item
Vacuum Pump
Voltage
230 / 400 V +/-10% (50 Hz), 265 / 460 V +/-10% (60 Hz)
Phase
Three
Weight
154 lb
Standards
UR
Compressor Type
Claw
Motor Type
Continuous-Duty TEFC
Duty Cycle
Continuous
Maximum Vacuum
18 in Hg
Series
Series C
Minimum Operating Temperature
41 Degrees F
Inlet Type
BSPP
Frequency
50 Hz, 60 Hz
Includes Motor
Yes
Output Power
1.5 kW
Lubrication Type
Splash Lubricated; Synthetic Oil
Maximum Operating Temperature
104 Degrees F
Life Expectancy
10 yr
Exhaust Location
Rear
Enclosure Type
TEFC
Maximum Speed
1,745 RPM
Sound Level
63 dBA
Inlet Gender
Female
Free Air Flow Rate
43.5 cfm
Current Rating
5.44 (230V) / 3.13 (400V) / 2.72 (460V)
Housing Material
Cast Iron
Impeller Material
Cast Iron
Mounting Style
Thru-Bolt
Enclosure Rating
IP55

Description

Vacuum Pump, Output Power 1.5 kW, Phase Three, Voltage 230 / 400 V +/-10 Percent (50 Hz), 265 / 460 V +/-10 Percent (60 Hz), Maximum Vacuum 18 in Hg, Inlet Size 1 1/2 in, Inlet Type BSPP, Inlet Gender Female
