Vacuum Pump, 5 hp, 230/460V AC, 30.9" L

  • Mfr # VCS 100
  • Zoro # G112120778
product price:
$
13,632.99
/ea
Additional $90.00 delivery surcharge applies per item.
See details

Key Features

Voltage
230/460V AC
Phase
Three
Weight
213.8 lb
Overall Length
30.9 in
Runs Dry
Yes
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
VCS 100
Zoro #
G112120778
UPC #
-
Country of Origin
Germany
Item
Vacuum Pump
Voltage
230/460V AC
Phase
Three
Weight
213.8 lb
Runs Dry
Yes
Inlet Type
NPT
Series
V-VCS
Rotor Material
Carbon Steel
Outlet Gender
Female
Duty Cycle
Continuous
Pump Type
Rotary Vane Vacuum
Maximum Operating Temperature
104 Degrees F
Maximum Vacuum
0.5 mbar
Outlet Type
NPT
Enclosure Type
TEFC
Sound Level
67 dBA
Current Rating
13/6.5 A
Frequency
50 Hz, 60 Hz
Valve Type
Ballast, Vacuum Non-Return
Magnetic Drive
No
Maximum Operating Pressure
500 mbar
Minimum Operating Temperature
53.6 Degrees F
Maximum Discharge Pressure
29.91 in Hg
Application
Drying, Hold-Down, Packaging, Pick & Place, Pneumatic Conveying
Inlet Gender
Female
Thermal Protection
None
Vane Material
Composite
Includes
Fine Mesh Filter, Gas Ballast Valve, Oil Separator, Oil/Air Heat Exchanger, Protective Cover, Vacuum Non-Return Valve on Suction Side
Filter Type
Fine Mesh
Oil Capacity
3 L
Submersible
No
Standards
UL Listed
Finish
Grey Paint
Output Power
5 hp
Bearing Type
Slide
Maximum Flow Rate
70.6 cfm

Description

Vacuum Pump, Output Power 5 hp, Phase Three, Voltage 230/460V AC, Maximum Flow Rate 70.6 cfm, Maximum Vacuum 0.5 mbar, Inlet Size 1 1/2 in, Inlet Type NPT, Inlet Gender Female, Outlet Size 2 in, Outlet Type NPT, Outlet Gender Female, Application Drying, Hold-Down, Packaging, Pick & Place, Pneumatic Conveying, Maximum Discharge Pressure 29.91 in Hg, Maximum Operating Pressure 500 mbar
