Enerpac

GBJ020A, 22 Ton, 5.91 in Stroke, Hydraulic Industrial Bottle Jack

product price: $420.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Promotion Restriction Not eligible for promotion
  • Lifting Capacity 20 ton
  • Lifting Height Min. 9 3/16 in
  • Lifting Height Max. 18 3/16 in
  • Base Size 6 3/4 in x 4 3/4 in
See all product information

Product Information

Dimensions

Lifting Height Min. 9 3/16 in
Lifting Height Max. 18 3/16 in
Base Size 6 3/4 in x 4 3/4 in
Extension Screw Length 3 in
Maximum Lift Height 18 1/8 in
Base Width 4 23/32 in
Minimum Height 9 7/32 in
Minimum Lift Height 9 1/8 in
Extended Height 18 1/16 in
Base Length 6 25/32 in
Plunger Diameter 2 in

Details

Promotion Restriction Not eligible for promotion
Lifting Capacity 20 ton
Application Lift
Standards ANSI PALD, CE Certified
Item High-Clearance Bottle Jacks
Construction Steel
Saddle Yes
Type Hydraulic
Hydraulic Stroke 5 15/16 in
Extension Screw 3 in
Jack Type Bottle Jack
Item Weight 23.3 lb
Stroke 5 29/32 in
Load Capacity 22 ton
Lifting Actuator Manual Handle
Handle Type Lower Handle
Body Material Steel
Includes Pump Handle
Features Automatic By-Pass Port to Prevent Over-Extension, High-Strength Beam and Pump Linkage for Long Life, Lower Handle Effort Reduces Operator Fatigue, Pump Swivels for Ease of Use, Improved Ergonomics, Safety Relief Valve to Prevent Overload, Thick Base Material with Large Area for increased Strength and Stability During Lifting
Power Source Mechanical
Series GBJ
Screw Extension 75 mm
Oil Capacity 17.75 oz
Stroke Ranges 5 in to 5.99 in

Description

High-Clearance Bottle Jacks, Jack Type Bottle Jack, Load Capacity 22 ton, Body Material Steel, Lifting Actuator Manual Handle, Minimum Lift Height 9 1/8 in, Maximum Lift Height 18 1/8 in, Power Source Mechanical, Minimum Height 9 7/32 in, Standards ANSI PALD, CE Certified, Base Length 6 25/32 in, Base Width 4 23/32 in, Extended Height 18 1/16 in, Extension Screw Length 3 in
