  5. Hydraulic Pressure Test Gauge, 0 to 40,000 psi psi, 6 1/2 in Dial, 1/4 in Cone, Bottom Location
Enerpac Hydraulic Pressure Test Gauge, 0 to 40,000 psi psi, 6 1/2 in Dial, 1/4 in Cone, Bottom Location T6010L - main

Hydraulic Pressure Test Gauge, 0 to 40,000 psi psi, 6 1/2 in Dial, 1/4 in Cone, Bottom Location

  • Mfr # T6010L

  • Zoro # G5511335

product price:  $2,919.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-1.50%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
Cone
Dial Size (In.)
6 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
T6010L
Zoro #
G5511335
UPC #
662005205585
Country of Origin
Germany

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
6 1/2 in
Flange Diameter
7.72 in
Nominal Dial Size
192 mm
Case Diameter
7.72 in
Case Depth
2.62 in
Nominal Dial Diameter
192 mm

Details

Item
Hydraulic Pressure Test Gauge
Accuracy
+/-1.50%
Process Connection Location
Bottom
Process Connection Type
Cone
Application
Test and Measurement
Gauge Case Material
403 Stainless Steel
Series
T - Gauge
Lens Material
Glass
Primary Pressure Range
0 to 40,000 psi
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
Yes
Calibration Certificate Included
No
Case Color
Metallic
Smallest Graduation
200 psi/20 Bar
Includes
Pressure Equalizing Membrane, Safety Blow-Out Disk
Gauge Primary Range Smallest Graduation
200
Gauge Application
Test System Gauge
Gauge Primary Range Numbered Graduations
5000
Case Material
403 Stainless Steel
Socket Material
403 Stainless Steel
Connection Type
BSPT
Type
Dry
Compatible Brand and Series
ENERPAC 83-011
Secondary Scale Minor Graduations
20
Includes Mounting Hardware
No
Compatible Manufacturer Model Number
43-704, 83-011
Primary Scale Numeric Increments
500
Process Connection Gender
Male
Includes Vent Plug
No
Field Fillable
No
Removable Bezel
No
Accuracy Scale
Full Scale
Requires Adapter
Yes
Pressure Gauge Type
Hydraulic Pressure Test Gauge
Secondary Scale Units
bar
Compatible Gauge Adapter
Enerpac 83-011
Dial Color
White
Primary Scale Minor Graduations
200
Pressure Range Type
Pressure
Scale Type
Dual
Gauge Case Liquid
None
Secondary Scale Numeric Increments
500
Vibration Resistance
None
Freeze Resistant Movement
No
Secondary Pressure Range
0 to 2,800 psi
Adjustable Pointer
No
Graduation Intervals
20 bar; 200 psi
Maximum Pressure
40000
Primary Scale Pressure Measurement - Maximum
40,000 psi
Process Media Temperature - Maximum
140 Degrees F
Primary Scale Pressure Measurement - Minimum
0 psi
NEMA Enclosure Rating
No Enclosure
Secondary Scale Pressure Measurement - Maximum
2,800 bar
Secondary Scale Pressure Measurement - Minimum
0 bar
Process Media Temperature - Minimum
-10 Degrees F
Compatible Cylinder/Press
ENERPAC 83-011
Compatible Cylinder Series
ENERPAC 83-011
Case Liquid
None
Compatible with Manufacturer Part Number
43-704, 83-011
Compatible Gauge Adapter Series
Enerpac 83-011

Description

Gauge, Gauge Type Test System, Dial Size 6.4 In., Range 0-40,000 psi, Connection Size 0.25 In. Cone, Connection Location Lower Mount, Accuracy +/-1.5 Percent, Case Material 403 Stainless Steel, Lens Material Glass, Series T
