Enerpac Hydraulic Cylinder Pressure Gauge, 0 to 15,000 psi psi, 2 1/2 in Dial, 1/4 in NPTF, Bottom Location G2536L - main

Hydraulic Cylinder Pressure Gauge, 0 to 15,000 psi psi, 2 1/2 in Dial, 1/4 in NPTF, Bottom Location

  • Mfr # G2536L

  • Zoro # G4712732

product price:  $205.00
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-1.50%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPTF
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
G2536L
Zoro #
G4712732
UPC #
662005223039
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Length
3.31"
Nominal Dial Size
2 1/2 in
Case Diameter
2.5 in
Case Depth
1.46 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Hydraulic Cylinder Pressure Gauge
Accuracy
+/-1.50%
Process Connection Location
Bottom
Process Connection Type
NPTF
Application
Hydraulics
Gauge Case Material
Stainless Steel
Series
G
Lens Material
Glass
Primary Pressure Range
0 to 15,000 psi
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
Yes
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
Yes
Includes
Pressure Equalizing Membrane, Safety Blow-Out Disk
Gauge Application
General Purpose
For Use With
Hydraulics
Gauge Filled With
Glycerin
Case Color
Metallic
Calibration Certificate Included
No
Case Material
Stainless Steel
Smallest Graduation
20 bar; 200 psi
Gauge Mounting Method
Lower Mount
Connection Type
NPTF
Adjustable Pointer
No
Includes Mounting Hardware
No
Primary Scale Minor Graduations
200
Removable Bezel
No
Gauge Case Liquid
Glycerin
Dial Color
White
Accuracy Scale
Full Scale
Secondary Scale Minor Graduations
20
Freeze Resistant Movement
No
Case Construction
Corrosion Resistant
Secondary Scale Units
bar
Field Fillable
No
Pressure Range Type
Pressure
Scale Type
Dual
Vibration Resistance
Liquid-Filled
Pressure Gauge Type
Hydraulic Cylinder Pressure Gauge
Secondary Pressure Range
0 to 1,000 psi
Includes Vent Plug
No
Compatible Gauge Adapter
Enerpac GA-3
Requires Adapter
Yes
Compatible Manufacturer Model Number
V-91
Compatible Brand and Series
ENERPAC V-91
Process Connection Gender
Male
Maximum Pressure
15,000 psi
Process Media Temperature - Maximum
140 Degrees F
IP Rating
IP66
Primary Scale Pressure Measurement - Maximum
15,000 psi
NEMA Enclosure Rating
4
Secondary Scale Pressure Measurement - Minimum
0 bar
Secondary Scale Pressure Measurement - Maximum
1,000 bar
Primary Scale Pressure Measurement - Minimum
0 psi
Process Media Temperature - Minimum
-4 Degrees F
Compatible Cylinder/Press
ENERPAC V-91
Case Liquid
Glycerin
Compatible Gauge Adapter Series
Enerpac GA-3
Compatible with Manufacturer Part Number
V-91
Compatible Cylinder Series
ENERPAC V-91

Description

Pressure Gauge, Liquid Filled, 2-1/2 In., 0 to 15,000 psi, Connection Size 1/4 In. MNPT, Connection Location Lower, Accuracy +/-1.5 Percent, Case Color Silver, Filled With Glycerin, Lens Material Glass, For Use With Hydraulics, Series G, Includes Safety Blowout Disc and Pressure Equalizing Membrane
