  6. ZA4204MX, Two Speed, Air Hydraulic Pump, 3/2 Manual Valve, 1.0 gal Oil, For Single-Acting Cylinders
Enerpac ZA4204MX, Two Speed, Air Hydraulic Pump, 3/2 Manual Valve, 1.0 gal Oil, For Single-Acting Cylinders ZA4204MX - main

ZA4204MX, Two Speed, Air Hydraulic Pump, 3/2 Manual Valve, 1.0 gal Oil, For Single-Acting Cylinders

  • Mfr # ZA4204MX

  • Zoro # G2855931

product price:  $6,855.00
/ea
Free Shipping & Returns

Key Features

Oil Capacity (Cu.-In.)
231 cu in
Reservoir Capacity (Gal.)
1 gal
Oil Displacement @ 0 PSI
110.00 cu in/min
Oil Displacement @ 10,000 PSI
80 cu in/min
Operating Air PSI
60 to 100
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZA4204MX
Zoro #
G2855931
UPC #
662005132638
Country of Origin
United States

Dimensions

Height (In.)
7.8 in
Length (In.)
5.8 in
Width (In.)
5.8 in
Media Intake Connection Size
3/8 in
Overall Height
20.5 in
Air Intake Connection Size
1/2 in
Overall Width
12.5 in
Overall Length
19.4 in

Details

Item
Air Hydraulic Pump
Oil Capacity (Cu.-In.)
231 cu in
Reservoir Capacity (Gal.)
1 gal
Oil Displacement @ 0 PSI
110.00 cu in/min
Oil Displacement @ 10,000 PSI
80 cu in/min
Operating Air PSI
60 to 100
Oil Displacement @ 5000 PSI
80 cu in/min
Air Consumption (SCFM)
20 to 100
Actuation Type
Pendant
Air Inlet NPT (In.)
1/2
Fluid Port NPT (In.)
3/8
Displacement @ 10,000 PSI
80 cu in/min
Treadle
Two Position
Features
Ergonomic Design, Pedal Lock Function, Pressure Relief Valve
Includes
Optional Heat Exchangers and Roll Cages Available
Usable Oil Capacity Vertical Mount
Pump
Capacity (PSI)
10,000
dBA
94 to 97
Built-In
One Factory Preset for Overload Protection and One Adjustable for Pre-Setting Maximum System Pressure, Sight or Level Gauge and Internal Relief Valves
Type
Air Powered
Oil Displacement @ 5000 psi
80 cu in/min
Displacement @ 5000 psi
110 cu in/min
Displacement @ 700 psi
675 cu in/min
Reservoir Capacity
231 cu in
Operating Pressure - Maximum
10,000 psi
Control Valve Function
Advance, Retract
Air Intake Pressure - Maximum
100 psi
Air Intake Connection Type
FNPT
Treadle Design
Two Position
Control Valve Type
2-Position, 3-Way
Air Consumption - Maximum
100 scfm
Sound Level - Minimum
94 dBA
Displacement @ 100 psi
850 cu in/min
Sound Level - Maximum
97 dBA
Flow Rate - Maximum
80 cu in/min

Description

Air Hydraulic Pump, Reservoir Capacity 231 cu in, Air Intake Pressure - Maximum 100 psi, Air Intake Connection Size 1/2 in, Operating Pressure - Maximum 10,000 psi, Displacement @ 100 psi 850 cu in/min, Displacement @ 5000 psi 110 cu in/min, Displacement @ 10,000 PSI 80 cu in/min, Sound Level - Maximum 97 dBA, Control Valve Type 2-Position, 3-Way, Actuation Type Pendant, Air Consumption - Maximum 100 scfm, Air Intake Connection Type FNPT, Control Valve Function Advance, Retract
