Watertight Locking Plug, L6-20P, 20 A, 250V AC, Single Phase, 2 Pole, Yellow

  • Mfr # 2312-PW6P-AM

  • Zoro # G007866095

product price:
$
52.69
/ea

Key Features

NEMA Plug Configuration
L6-20P
Phase
Single
Number of Poles
2
Number of Wires
3
Number of Blades
3
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
2312-PW6P-AM
Zoro #
G007866095
UPC #
782862899823
Country of Origin
United States

Dimensions

For Minimum Cable Diameter
0.47 in
For Maximum Cable Diameter
0.72 in
Cord Size
0.470 in to 0.720 in

Details

Item
Watertight Locking Plug
NEMA Plug Configuration
L6-20P
Current Rating
20 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Number of Blades
3
Wiring Style
Standard
Connection Orientation
Straight
Shrouded
Yes
Housing Color
Yellow
Standards
ANSI/UL 498 File E17740, CSA Certified C22.2 No. 42, NSF/ANSI/3-A 14159-1
Resistance Properties
Antimicrobial, Corrosion Resistant, Watertight
For Environment
Washdown
Grade
Industrial
Application
Any environment that requires a watertight seal of a plug and connector to prevent water ingress. Applications range from a construction site to an entertainment venue and a drop down connector in a food processing plant during a Washdown procedure.
Housing Material
Thermoplastic Elastomer
Special Features
Corrosion resistant
Market
Industrial
IP Rating
IP69K
Material
Thermoplastic Elastomer
Sub Brand / Trademark
Perma-Kleen
Blade Style
Straight
Device Type
Plug
Amps
20
Antimicrobial
Yes
Wire Connection Type
Screw Terminals
Midget Locking
No
Series
Perma-Kleen
Horsepower Rating
Not Rated
Power and Ground Indicating Light
No

Description

Locking Plug, Current Rating 20 A, Housing Color Yellow, Housing Material Thermoplastic Elastomer, NEMA Plug Configuration L6-20P, Number of Blades 3, Number of Poles 2, Phase Single, Resistance Properties Antimicrobial, Corrosion Resistant, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.72 in, For Minimum Cable Diameter 0.47 in, Grade Industrial, Horsepower Rating Not Rated, IP Rating IP69K, Market Industrial, Midget Locking No
