Shop EXTECH

Digital Clamp Meter, Backlit LCD, 400 A, 1.3 in (33 mm) Jaw Capacity, CAT III 600V Safety Rating

  • Mfr # EX623

  • Zoro # G0953601

product price:  $262.99
/ea
Free Shipping & Returns

Key Features

Digital/Analog
Digital
Max. AC Amps
400
Clamp Meter Jaw Style
Clamp On
Max. DC Volts
600 V
Max. Ohms
40 megaohm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
EX623
Zoro #
G0953601
UPC #
793950376232
Country of Origin
China

Dimensions

Max. Conductor Size
500 kcmil
Manufacturers Warranty Length
1 yr
Overall Height
9 in
Battery Size
9V
Overall Width
3.1 in
Maximum Conductor Size
500MCM

Details

Item
Digital Clamp Meter
Digital/Analog
Digital
Max. AC Amps
400
Clamp Meter Jaw Style
Clamp On
Max. DC Volts
600 V
Max. Ohms
40 megaohm
Jaw Capacity
1.3 in (33 mm)
Temp. Range
-58 Degrees to 1832 Degrees F
Safety Rating
CAT III 600V
Display
Backlit LCD
Jaw Opening
1.25 in
Max. DC Amps
400
Max. AC Volts
600 V
Calibration Frequency
50 to 60 Hz
Audible Continuity
Yes
Operating Temp.
14 Degrees to 122 Degrees F
Capacitance
40
Non-Contact Voltage Detector
Yes
Diode Test
Yes
Special Features
8 to 1 Distance to Target Ratio, Built-In Non-Contact IR Thermometer with Laser Pointer for Locating Hot Spots (up to 518 Degrees F/270 Degrees C), DC micron A Multimeter Function for HVAC Flame Rod Current Measurements, Dual Type K Thermocouple Input with Differential Temperature Function (T1, T2, T1-T2), True-RMS Measurements for Accurate AC Voltage and Current Measurements
Counts
4,000
Inrush
Yes
Peak Hold
Yes
Includes
(2) Type K Bead Wire Probes, Carrying Case, Test Leads
AC Current Accuracy
+/-1.5%
Data Hold
Yes
Thermometer Type
Type K Thermocouple
Frequency Counter
1 Hz to 40 MHz
Auto Power Off
Yes
AC Response
TRMS
Battery Type
9V
Auto Ranging
Yes
Maximum DC Voltage Measurement
600 V
Maximum Operating Temperature
1,832 Degrees F
Minimum Operating Temperature
-58 Degrees F
Battery Access
Yes
Maximum Resistance Measurement
40 megaohm
Maximum AC Voltage Measurement
600 V
Maximum AC Current Measurement
400 A
Parameters Measured
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Duty Cycle, Frequency, Resistance, Temperature
Batteries Included
Yes
Maximum Frequency Measurement
40 MHz
AC Response Calculation
TRMS
Inrush Current Measurable
Yes
Calibration Certificate Included
No
Display Type
Backlit LCD
Maximum DC Current Measurement
400 A
Instrument Counts
40,000
Maximum Capacitance Measurement
40 mF
Capacitance Measurement Resolution
40 mF
Frequency Measurement Resolution
40 MHz
Resistance Measurement Resolution
40 microohm
Jaw Style
Clamp
Basic AC Current Accuracy
+/-1.50%
Includes Auto Sensing
No Auto Sensing Included
CAT Safety Rating
CAT III 600V
Jaw Detachability
Fixed
Temperature Types Measured
Infrared Temperature, Temperature K

Description

Digital Clamp Meter, Audible Continuity Yes, Safety Rating CAT III 600V, AC Response Calculation TRMS, Maximum AC Current Measurement 400 A, Maximum AC Voltage Measurement 600 V, Maximum DC Current Measurement 400 A, Maximum DC Voltage Measurement 600 V, Parameters Measured AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Duty Cycle, Frequency, Resistance, Temperature (IR), Temperature (K), Jaw Opening 1.25 in, Jaw Style Clamp On, Calibration Certificate Included No
