Finish Thompson

Drum Pump, 115VAC, 1/3 HP, 60 Hz

original price: $1,129.79
19% off
new price: $909.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • For Use With Mild Corrosive Chemicals
  • Housing Material 316 Stainless Steel
  • Includes Clamp, Hose, Motor, Pump
  • Inlet Size 1-1/4"
  • Motor Type Universal AC/DC
See all product information

Product Information

Dimensions

Inlet Size 1-1/4"
Discharge Tube Outlet OD Size 1"
Manufacturers Warranty Length 1 yr.
Suction Tube Outlet O.D. Size 1-1/4"
Discharge Tube Length 5 ft.
Outlet Size Espiga de 3/4"
Hose Length 60 in
Discharge Tube Outlet ID Size 3/4"
Suction Tube Length 40 in
Overall Length 48 5/8 in
Cord Length 12 ft
Height Above Container 8 5/8 in
Hose Inside Dia. 3/4 in
Hose Outside Dia. 1 in
Bung Connection Dia. 2 in
For Container Size 55 gal

Details

For Use With Mild Corrosive Chemicals
Housing Material 316 Stainless Steel
Includes Clamp, Hose, Motor, Pump
Motor Type Universal AC/DC
Voltage 115VAC
Action Type Piston
Max. Flow GPM 17 gpm
Application For Transferring Antifreeze Solvents, Thinners, Automotive Additives, industrial Chemicals, Oil Based Fluids and Other Non Corrosive Fluids
Standards CSA Certified
Hz 60
Max. Temp. 212 Degrees F
Hose Material PVC
Wetted Materials 316 Stainless Steel, ETFE, FKM, PTFE
Max. Pressure 8.7 psi
Max. GPM for Water 17
Motor Enclosure ODP
pH Range 6 to 10
Max. Viscosity 300 cps
Seal Material FKM
GPM 17
DEF Compatible No
Max. Head 20 ft.
Type Motor and Tube
Max. GPM for Oil 7 a 100 CPS
Discharge Tubing Material PVC
Item Electric Operated Drum Pump
Phase 1
HP 1/3
Agency Compliance CSA
Suction Tube Type Constant
Metered No
Pump Body Material 316 Stainless Steel
Max. Liquid Temp. 212 Degrees F
Suction Tube OD 1 1/4 in
Frequency (Hz) 60 Hz
Discharge Tube Outlet ID 3/4 in
Diesel Exhaust Fluid Compatible No
Duty Cycle Continuous
Pump Connection Type Smooth Bore
Includes Nozzle No
Full Load Amps 2.0 A
Includes Discharge Hose Yes
Variable Speed Yes
Thermal Protection No
Self-Priming Yes
Suction Tube Material 316 Stainless Steel
Motor HP 1/3 hp
Discharge Connection Type Hose Barb
Includes Bung Adapter No
Not Recommended Chemicals Acetic Acid (Glacial), Acetone, Ammonia (Liquids), Anhydrous Ammonia, Biodiesel, Cyclohexane, DEF, Diesel Fuel, E85, Ethyl (Ethanol), Ethyl Acetate, Formaldehyde, Formaldehyde 40%, Gasoline, Glycerin, Heptane, Hexane, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Hydrazine, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Isopropyl (Isopropanol), Kerosene, Lacquer Thinners, Methyl (Methanol), Methyl Ethyl Ketone (MEK), Naphtha, Paint Thinner, Sodium Hypochlorite/Bleach (to 20%), Stoddard Solvent (Mineral Spirits), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Sulfuric Acid (to 10%), Toluene, Turpentine, Windshield Washer Fluid, Xylene
Max. Flow Rate 17 gpm
Plug Type NEMA 5-15
Discharge Tube Outlet OD 1 in
Max. Head - Pumps 20 ft
Number of Phases 1
Includes Suction Tube Yes
Motor RPM 8000 to 14,000
Housing Material - Pumps 316 Stainless Steel
For Container Type Drum
Min. Fluid Temp. 0 Degrees F
Compatible Chemicals Acetic Acid 20%, Acetic Acid 80%, Ammonium Hydroxide, Antifreeze (Coolant), Automatic Transmission Fluid, Brake Fluid, Calcium Chloride, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Citric Acid 50%, Deionized Water, Ethylene Glycol, Formic Acid, Fresh Water, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Phosphoric Acid (40% Solution), Potassium Hydroxide (50%), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Trichlorethylene (50%)
Food Grade No
Max. Head Pressure 8.7 psi
Series EF
Hose Tube Material PVC
For Media Type Acetic Acid, Ammonium Hydroxide, Antifreeze, Automatic Transmission Fluid, Brake Fluid, Calcium Chloride, Chromic Acid, Citric Acid, Ethylene Glycol, Formic Acid, Nitric Acid, Phosphoric Acid (40% Solution), Potassium Hydroxide (50%), Sodium Bicarbonate, Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide, Trichlorethylene, Water
Noise Level 74 db
Suction Tube ID 1 1/4 in
Max. Fluid Temp. 212 Degrees F
Power Source Electric
Runs Dry No
Rated Voltage 115V AC
Max. Outlet Pressure 8.7 psi
Explosion Proof No
Grease NT
Gear Lube NT

Description

Electric Operated Drum Pump, Hose Inside Dia. 3/4 in, Max. Head Pressure 8.7 psi, Max. Outlet Pressure 8.7 psi, For Use With Mild Corrosive Chemicals, Rated Voltage 115V AC, Plug Type NEMA 5-15, Suction Tube OD 1 1/4 in, Hose Length 60 in, Suction Tube Length 40 in, Cord Length 12 ft, Includes Bung Adapter No, Runs Dry No, Thermal Protection No, Frequency (Hz) 60 Hz, Power Source Electric, Variable Speed Yes, Includes Discharge Hose Yes, Self-Priming Yes
