  5. Digital Test Compound Gauge, -14 to 0 to 3000 psi, 3 3/4 in Dial, 1/4 in NPT, Bottom Location
Fluke Digital Test Compound Gauge, -14 to 0 to 3000 psi, 3 3/4 in Dial, 1/4 in NPT, Bottom Location FLUKE-700G29 - main

Digital Test Compound Gauge, -14 to 0 to 3000 psi, 3 3/4 in Dial, 1/4 in NPT, Bottom Location

  • Mfr # FLUKE-700G29

  • Zoro # G4598054

product price:  $1,502.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-0.05%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
3 3/4 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
FLUKE-700G29
Zoro #
G4598054
UPC #
095969611107
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
3 3/4 in
Connection Size
1/4 in
Display Screen Height
0.65 in
Case Diameter
3.75 in
Nominal Dial Size
3 3/4 in
Digit Height
0.65 in
Manufacturer Warranty Length
3 yr
Battery Size
AA

Details

Item
Digital Test Compound Gauge
Accuracy
+/-0.05%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Hydraulics, Pneumatics
Gauge Case Material
Cast Zinc Aluminum
Series
700G
Primary Pressure Range
-14 to 0 to 3000
Primary Scale Units
psi
IP/NEMA Rating
IP67
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Socket Material
Stainless Steel
Agency Compliance
CSA: Class 1, Div2, Groups A-D rating, ATEX: rating II 3 G Ex nA IIB T6
Digital Pressure and Vacuum Gauge Type
Digital Compound Gauge
Case Material
Cast Znal
Calibration Certificate
NIST Traceable
Includes
Manual on CD-ROM in 14 languages
Display
Multiline LCD
Powered By
(3) AA Batteries
Peak Hold
No
Case Color
Silver
For Use With
Any Liquids or Gasses Compatible with 316 Stainless Steel
Display Units
bar, psi
Number of Display Digits
5
Wetted Materials
Stainless Steel
Connection Type
MNPT
Standards
ATEX, CSA
Display Resolution
0.01 bar
Pressure Range Type
Compound
Process Temperature Range
-14 Degrees to 131 Degrees F
Includes Calibration Certificate
NIST with Data
Includes Mounting Hardware
No
Weatherproof
No
Accuracy Grade Gauge Type
Process
Ambient Operating Temperature Range
-10 Degrees to 55 Degrees C, 14 Degrees to 131 Degrees F
Burst Pressure
10,000 psi
Languages
English
Includes Rubber Boot
No
Compatible Brand and Series
Fluke 700 Series
Battery Run Time
1,500 hr
Compatible Process Media
Any Clean Dry Non-Corrosive Gas, Any Liquids or Gases Compatible With 316 Stainless Steel, Any Non-Flammable, Non-Toxic, Non-Explosive, Non-Oxidizing Liquid or Gas Compatible With 316 Stainless Steel
Pressure Gauge Type
Test Pressure Gauge
Includes Batteries
No Batteries Included
Adjustable Set Points
No
Backlit Screen
Yes
Bar Graph
20 Segments
Case Construction
Rugged
Primary Display Units
psi
Case Shape
Round
Power Source
Battery
Auto-Shutoff
Yes
Memory Storage Capacity
8493 Readings
Compatible Manufacturer Model Number
700HTPK, 700PTPK
Non-Sparking
No
Primary Display Range
-14 to 3,000
Display Range
-14 to 3,000 psi
Process Connection Gender
Male
Low Battery Indicator
Yes
Number of Digits
5
Display Screen Type
LCD
Sensor Material
Silicon Substrate
Battery Life
1,500 hr
Automatic Shut-Off Time
1 min, 30 min
Display Type
LCD
Operating Temperature Range
-14 Degrees to 131 Degrees F
Process Media Temperature - Minimum
-14 Degrees F
Includes Low Battery Indicator
Low Battery Indicator
Hazardous Location Specification
Class I, Div 2, Group A, D
Pressure Measurement - Minimum
-14 psi
Compatible with Manufacturer Part Number
700HTPK, 700PTPK
Pressure Measurement - Maximum
3,000 psi
Compatible with Series
Fluke 700 Series
NEMA Enclosure Rating
No Enclosure
Pressure Measuring Units
bar, psi
IP Rating
IP67
Accuracy Grade
Not Graded
Number of Batteries Required
3
Vacuum Measurement - Maximum
10,000 psi
Resistance Properties
Explosion Proof
Vacuum Measurement - Minimum
-14 psi
Process Media Temperature - Maximum
131 Degrees F
Operating Temperature - Minimum
14 Degrees F

Description

Digital Test Compound Gauge, Accuracy +/-0.05 Percent, Gauge Case Material Cast Zinc Aluminum, Nominal Dial Size 3 3/4 in, Lens Material Not Applicable, IP/NEMA Rating IP67, Hazardous Location Rating Not Rated, Compatible Process Media Any Clean Dry Non-Corrosive Gas, Any Liquids or Gases Compatible With 316 Stainless Steel, Any Non-Flammable, Non-Toxic, Non-Explosive, Non-Oxidizing Liquid or Gas Compatible With 316 Stainless Steel, Sensor Material Silicon Substrate
